439 mm
17.3 in
365 mm
14.4 in
707 mm
27.8 in
System Type: Self powered 15”, two-way, bass-re�ex
Maximum SPL Output: 127 dB
Frequency Range (-10 dB): 39 Hz - 20 kHz
Frequency Response (±3 dB): 50 Hz - 20 kHz
EQ: 3 Parametric EQ’s, High and Low Shelf (Available via Bluetooth app only)
Ampli�er Design: High Ef�ciency Class D
System Power Rating: 1000W Peak (700 LF + 300HF); 500W Continuous (350W LF + 150W HF)
Input Impedance: 20K ohms (Balanced)
Line Input Gain: In�nity to +26.8dB (+14dBu max input level)
Mic Input Gain: In�nity to +29dB (in addition to line input gain)
Connectors: 2 x Balanced XLR-1/4” combination inputs; 1 x male XLR loop thru out
LED Indicators: Power, Bluetooth, EQ Preset, EQ +, Signal CH1, Signal CH2, Limit
Cooling: Passively Cooled (No Fan)
AC Power Input: 100-120VAC 50/60Hz; 230-240VAC 50/60Hz
AC Power Consumption (120VAC): 1/8th Power – 1.14A (Max), 1/4th Power – 1.71A (Max), 1/3rd Power – 2.03A (Max)
LF Driver: 1 x JBL 615H 380mm (15”) woofer with 2” voice coil
HF Driver: 1 x JBL 2414H-1 25.4mm (1”) annular polymer diaphragm, neodymium compression driver
Coverage Pattern: 90º H x 60º V
Crossover Frequency: 1.8kHz
Material: Polypropylene, multi-purpose main & monitor
Suspension / Mounting: 36mm pole socket with stabilizing screw, 3 x M10 suspension points
Handles: One left, one right, one top, one bottom (4 total)
Finish: Black Granite
Grille: Powder coated perforated steel with acoustically transparent screen backing
Dimensions (H x W x D): 707mm x 439mm x 365mm (27.8” x 17.3” x 14.4”)
Gross Weight: 17.69 kg (39 lbs)
