JBL HARMONY - Page 35

R326, R327, R382 QCF0851-471 CHIP RES. 470 OHM 1/8W 5% 3
1206 SMT TYPE
R337, R827 QCF0851-822 CHIP RES. 8.2K OHM 1/8W 5% 2
1206 SMT TYPE
R338 QCF0851-134 CHIP RES. 130K OHM 1/8W 5% 1
1206 SMT TYPE
R348 QCF0851-153 CHIP RES. 15K OHM 1/8W 5% 1
1206 SMT TYPE
R363, R366, R831, QCF0851-562 CHIP RES. 5.6K OHM 1/8W 5% 4
R896
R368 QCF0851-821 CHIP RES. 820 OHM 1/8W 5% 1
1206 SMT TYPE
R371 R804 QCF0851-105 CHIP RES. 1M OHM 1/8W 5% 2
1206 SMT TYPE
R378, R379, R380, QCF0851-561 CHIP RES. 560 OHM 1/8W 5% 3
1206 SMT TYPE
R806 QCF0851-123 CHIP RES. 12K OHM 1/8W 5% 1
1206 SMT TYPE
R813 QCF0851-334 CHIP RES. 330K OHM 1/8W 5% 1
1206 SMT TYPE
R814 QCF0851-474 CHIP RES. 470K OHM 1/8W 5% 1
1206 SMT TYPE
R821 QCF0851-824 CHIP RES. 820K OHM 1/8W 5% 1
1206 SMT TYPE
R823 QCF0851-514 CHIP RES. 510K OHM 1/8W 5% 1
1206 SMT TYPE
R825 QCF0851-823 CHIP RES. 82K OHM 1/8W 5% 1
1206 SMT TYPE
R829 QCF0851-124 CHIP RES. 120K OHM 1/8W 5% 1
1206 SMT TYPE
R832, R859, R860 QCF0851-332 CHIP RES. 3.3K OHM 1/8W 5% 3
1206 SMT TYPE
R841, R842, R843, QCF0851-753 CHIP RES. 75K OHM 1/8W 5% 4
R844 1206 SMT TYPE
R845, R846, R847, QCF0851-363 CHIP RES. 36K OHM 1/8W 5% 4
R848 1206 SMT TYPE
R849, R850, R851, QCF0851-563 CHIP RES. 56K OHM 1/8W 5% 4
R852 1206 SMT TYPE
R899 QCF0851-682 CHIP RES. 6.8K OHM 1/8W 5% 1
1206 SMT TYPE
Transistors
Q209, Q210, Q215, RAN0945-001 XISTR NPN 2SC945P NEC 11
Q301, Q501, Q805,
Q806, Q807, Q811,
Q812, Q816
Q201, Q808 RAP0733-001 XISTR PNP “2SA733Q,P NEC AI” 2
Q801, Q802, Q803, RAP0952-001 XISTR PNP 2SA952 NEC 6
Q813, Q814, Q818
Q810 RHP0772-001 XISTR PNP 2SB772P/Q NEC 1
Miscellaneous
BT201 FBE0030-001 LI BATTERY LITHIUM RECHARG. 1
VL1220/IHF 7mAH
HEAT SINK GAL0074-002 (A) AL NATURAL COLOR 1
HEAT SINK GAL0087-002 (B) AL NATURAL COLOR 1
JK101 CJF0002-001 ANT JACK FM ANT JACK (F) TYPE 1
JK102 CJM9380-038 PHONE JACK 3.5 DIA 1
J301 CTP0005-001 JACK RCA 2P JACK 1
JYE TAI(RJ-1020-009)
L801, L802, L804 SAC7414-100 CHOKE 10uH AI 3
TU101 WTP0002-002 TUNER PACK FAE203-A02 (FCC) 1
TUNER PACK JQC6070-450 CRYSTAL 4.5000 MHZ HC-49/U 1
TUNER PACK
X201 JQC607A-419 CRYSTAL 4.194304 MHz (TXC) 1
X202 JQC6070-327 CRYSTAL 32.768 KHZ C-001R 1
X801 JQC6070-338 CRYSTAL 33.8688 MHZ HC-49/U 1
GSE0175-001 IC BRACKET SECC t1.0mm IC501 1
GTN0033-001 HEAT SINK TIN HEAT SINK 1
TO TUNER PACK
GTN0037-001 COVER TUNER COVER A, 1
TUNER PACK-1
GTN0038-002 TUN COVER, TUNER COVER B 1
HARMONY (NEW) H/SINK TO
PCB-2
H120301-106 SCREW T3.0x0.5pxL6.0 mm 2
PAN HEAD NICKEL H/SINK(F)
TO H/SINK(B)-3
H120301-308 SCREW T3.0x0.5pxL8.0 mm 3
PAN HEAD BLACK IC TO H/SINK-2
H120301-314 SCREW T3.0x0.5pxL14.0mm 2
PAN HEAD BLACK
CONTROL PCB ASSY
Capacitors
C210, C211 PRD3545-102 COND DISC 1000pF 50V 10% Y5P 2
C271, C272 PRA3952-101 COND ELECT 100 uF 16V 20% 2
MINI SIZE
C273, C274 PAU3963-104 COND TUBUL 0.1 uF 25V +80-20% 2
F(Y5V)
C275 PAU3545-101 COND TUBUL 100 pF 50V 10% 1
B(Y5P)
C276 PRA3952-220 COND ELECT 22 uF 16V 20% 1
MINI SIZE
Diodes
D206, D207, D271 RAD4148-001 DIODE SW 1N4148 3
ZD205 RAZ0859-068 DIODE ZENR 5.0-5.2V 0.5W 1
HITACHI HZ5C-2
Integrated Circuit
IC202 RCI5824-001 IC 64 PIN LC75824 SANYO 1
204 SEG LCD DRIVER
Resistors
R202, R218, R283 QAF0650-471 RESISTOR 470 OHM 1/6W 5% CF 3
R203, R204, R219, QAF0650-391 RESISTOR 390 OHM 1/6W 5% CF 4
R220
R205, R221 QAF0650-561 RESISTOR 560 OHM 1/6W 5% CF 2
R206 QAF0650-681 RESISTOR 680 OHM 1/6W 5% CF 1
27
CD Player/Tuner Stereo System HARMONY
Ref. # Part Number Description Qty Ref. # Part Number Description Qty
