R207 QAF0650-751 RESISTOR 750 OHM 1/6W 5% CF 1
R208 QAF0650-821 RESISTOR 820 OHM 1/6W 5% CF 1
R209 QAF0650-122 RESISTOR 1.2K OHM 1/6W 5% CF 1
R210 QAF0650-152 RESISTOR 1.5K OHM 1/6W 5% CF 1
R211 QAF0650-202 RESISTOR 2K OHM 1/6W 5% CF 1
R212 QAF0650-302 RESISTOR 3K OHM 1/6W 5% CF 1
R213, R280, R282 QAF0650-472 RESISTOR 4.7K OHM 1/6W 5% CF 3
R214 QAF0650-822 RESISTOR 8.2K OHM 1/6W 5% CF 1
R222, R223, R224 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF 3
R225 QAF0650-399 RESISTOR 3.9 OHM 1/6W 5% CF 1
R226 QAF0650-222 RESISTOR 2.2K OHM 1/6W 5% CF 1
R271 QAF0650-100 RESISTOR 10 OHM 1/6W 5% CF 1
R272 QAF0650-470 RESISTOR 47 OHM 1/6W 5% CF 1
R273 QAF0650-104 RESISTOR 100K OHM 1/6W 5% CF 1
R276 QAF0650-564 RESISTOR 560K OHM 1/6W 5% CF 1
R277, R278, R279 QAF0650-102 RESISTOR 1K OHM 1/6W 5% CF 3
R281 QAF0450-300 RESISTOR 30 OHM 1/4W 5% CF 1
VR201 MSR1624-202 R-ENCODER EC16B24202 ALPS 1
16 mm WITH DETENT
Transistors
Q202, Q203, Q204, RAN0945-001 XISTR NPN 2SC945P NEC 4
Q207
Q205 RAP0952-001 XISTR PNP 2SA952 NEC 1
Q208 RAN2001-001 XISTR NPN 2SC2001L NEC 1
Miscellaneous
TO LCD IVS0009-002 FELT 82.0x11.0xT0.5 mm 1
HOLDER BACK WITH ADHESIVE
TO LCD IVS0009-003 FELT 23.0x11.0xT0.5 mm 2
HOLDER BACK WITH ADHESIVE
LCD GFI0013-003 FIBER PLT 25X2.5X1.0mm 2
HOLDER
GTN0041-001 LCD HOLDER 1
LP201 KDG0024-002 LED ARRAY 1
D204 KEM0002-003 LED 3 DIA LED TWO COLOR 1
GREEN/YELLOW CHANGE
DSP201 KLD0027-002 DISPLAY LC FT-068PAT PICVUE 1
HARMONY (NEW)
SN201 RHO0638-009 IRT SENSOR PIC-28043TE2 L=16mm1
KODENSHI KOT62104344
500331298B3 CON/WIRE 3 COND 120mm P=2mm 1
26 AWG, RB205 TO SNOOZE /
ALARM CONTROL PCB CN205
500331698B3 CON/WIRE 3 COND 160mm P=2mm
RIBBON UL2468 26 GA 1,
RB904 TO MAIN PCB CN904
5003A1698B3 CON/WIRE 10 COND 160mm P=2mm
RIBBON UL2468 26 GA 1,
RB202 TO MAIN PCB CN202
TA203,TA204, TA205, MAT2029-001 AI TACT SW 5.0mm 160 gf 16
TA206,TA207,TA208, ALPS SKHVBE3520
TA209, TA210, TA211,
TA212, TA213, TA214,
TA217, TA218, TA219,
TA220
APE0200-021 R-ENCODER PCB 1
APE0200-031 ALARM ASSEMBLY PCB 1
APE0200-042 AC-DC POWER ASSEMBLY PCB 1
Alarm Assy
CN205 CCN7879-037 CONNECTOR 3 PIN PITCH=2.0mm 1
SIDE ENTRY TYPE
TA201, TA202, TA221 MAT2029-001 AI TACT SW 5.0mm 160gf 3
ALPS SKHVBE3520
SW PCB ASSY
CN101 CCN7879-036 CONNECTOR 2 PIN PITCH=2.0 mm 1
SIDE ENTRY TYPE
SW101 MSS9477-034 SW SLIDE 1
R105 QAF0650-912 RESISTOR 9.1K OHM 1/6W 5% CF 1
AC INPUT ASSY
Connectors
CN503, CN503A CCN1500-015 CONNECTOR B 4B-XH-A 4 PIN 2
POST BASE TOP
CN901 CCN3962-924 CONNECTOR 4 PIN SIDE BASE 1
REMOVED PIN2&3
CN902 CCN3962-002 CONNECTOR 2 PIN CL3962WVO 1
P=3. 96mm POST BASE TOP
CN903A CCN7879-030 CONNECTOR J.S.T. 2.0mm PH 1
B10B-PH-K TOP SIZE
CN905B CCN3962-004 CONNECTOR 4 PIN CL3962WVO 1
PITCH=3.96mm
CN907 CCN3962-003 CONNECTOR 3 PIN CL3962WVO 1
Capacitors
C901 PRD3965-104 COND DISC 0.1uF 50V +80-20% 1
Y5V/Z5V
C902 PVS0003-103 COND SAFE 0.01uF 250V 20% 1
UL/CSA/VDE/SEMKO
RB905A TO POWER PCB CN905B
C904 PVE3954-472 COND ELECT 4700uF 35V 20% 1
C905 PVE3953-102 ELECT 1000uF 25V 20% D=10 1
C924, C929, C930 PRD3965-104 COND DISC 0.1uF 50V +80-20% 3
Y5V/Z5V
C926 PRE3952-471 COND ELECT 470uF 16V 20% 1
C927, C928 PRD3545-221 COND DISC 220pF 50V 10% 2
Y5P II D=5
C931 PRE3951-221 COND ELECT 220uF 10V 20% 1
C933 PRE3952-221 COND ELECT 220uF 16V 20% 1
C934 PRE3955-109 COND ELECT 1uF 50V 20% 1
C935, C936, C937, PEP2635-224 COND METAL .22uF 50V 5% 4
C938 TAPPING MINI SIZE T=mm
28
