JBL LS Series User Manual

Part number Description Qty Reference Designator
CLASS D PCB ASS'Y (RECOMMENDED REPLACE ENTIRE MODULE PART# 051-A05022C-E)
192-09210376
q
s-e SMD TRANSISTOR 2SA1037K-T146Q/RROHM
(
RoHS
)
2 Q7,Q9,
192-09215146rs-e SMD TRANSISTOR 2SA1514K-T146R ROHM
(
RoHS
)
1 Q3,
192-1582N5401-E TRANSISTOR FSC 2N5401 AI-PNP 350V500mA TO-92
(
RoH
S
1 Q6B,
192-232irf9640-e FET IRF9640 IR P-CH TO220
(
RoHS
)
2 Q10,Q10B,
192-233F640N-E TRANSISTOR IRF640N INTERNATIONAL
(
RoHS
)
1 Q11,
197-03rls4148s-e SMD DIODE RLS4148-TE11 ROHM
(
RoHS
)
8 D1,D2,D3,D4,D5,D5B,
199-15000563S-E SMD ZENER 5.6V 5% PHILIPSBZX84-C5V6
(
RoHS
)
2 Z1,Z2,
199-1500120s-e SMD ZENER 12V 5% PHILIPSBZX84-C12
(
RoHS
)
4 Z3,Z4,Z5,Z6,
Miscellaneou
s
122-13151K0190-E CHOKE SA-500-280
(
PT1601B*151MAA
)
(
RoHS
)
1 L1,
122-14300K4-E Ferrite core LD1215*300KU±10% RoH
S
1 L2,
175-9F02H02-E WIRE CONNECTOR&BASE 2PIN PITCH=2.54mm
(
RoHS
)
1 HDR3,
175-9F03H020-E WIRE CONNECTOR&BASE 3PIN PITCH=2.54mm
(
RoHS
)
2 HDR1,HDR2,
359-FIB-00125-E FIBER WASHER 10*5*0.5T
(
RoHS
)
2
MISCELLANEOUS/MECHANICAL
150-r1107011-e POWER TRANSFORMER TT0930505260
(
RoHS
)
1
152-U60201A02-E
A
C LINE CORD 6FT UL 2PIN
(
RoHS
)
1
153-VPST101S2-E
A
C OUTLET&SOCKET VDE 2PINS INLET SOCKET
(
RoHS
)
1
154-K31505T0-E FUSE 3.15A 250V 30mm UL/CSA /PSE
(
RoHS
)
1
155-630R345B-E FUSE HOLDER UL/CSA
ψ
6*30mm R3-45 B
(
RoHS
)
1
162-10100023-e WIRE UL/CSA 1617 #22 100mm BLK
(
RoHS
)
1
162-10151001-e WIRE UL1617 150mm 22AWG BROWN 6:6
(
RoHS
)
1
162-5016d001-e WIRE 24# 160mm BLACK
(
RoHS
)
1
166-5070A4BD-E SPKR WIRE 700mm #18 UL1015#205*0.5t BLACK/#250*0.8t
R
1
180-PRF1003B-E POWER SWITCH ROCKER RF-1003-BB210
(
RoHS
)
1
193-0s4211-e INSULATOR
(
INSULATION SPACER
)
42*11
(
RoHS
)
1
193-201612tr-e INSULATOR T0-220 16mm*12mm
(
RoHS
)
3
236-AL-05001-0LAE RITAINER
(
RoHS
)
1
302-AL-05130-1BAE REAR BOARD 300*200*2.5mm BLACK
(
RoHS
)
1
306-ABS-05081-0BA
E
REAR HOUSING 198*298*102mm 8PIECE EVA
(
RoHS
)
1
311-ABS-00028-0BA
E
PLASTIC KNOB 46077-W P.V.C.
(
RoHS
)
2 LEVEL, CROSSOVER
323-AL-05000-0LAE HEAT SINK
(
RoHS
)
1
325-FE-00400-0LAE PCBFLOOR STAND 58*9*13.5T
(
RoHS
)
1
333-EVA-00188-0BA
E
EVA GASKET 170x5x1t
(
RoHS
)
1
333-EVA-00220-0BA
E
EVAGASKET BORDER LONG 225*15*1t UL
(
RoHS
)
1
333-EVA-00866-0BA
E
FIREPROOFING EVA 48*18*1.5T
(
RoHS
)
1
333-SPG-00860-0BA
E
FIREPROOFING COTTON 450*50*5T
(
RoHS
)
1
335-NYL-00002-0BA
E
LINE CORD 扣 4K-4 NO-BB
(
RoHS
)
1
336-RUB-05103-0BA
E
RUB PAD 97*16*3.0T BLACK
(
RoHS
)
2
350-EM04012D024-E 4￠*12WOOD SCREW ELECTRIC BLACK
(
RoHS
)
4
351-AM03008A078-E M3*8 MACHINE SCREW PLATTING NICKEL
(
RoHS
)
4
351-AM03008A079-E M3*8 MACHINE SCREW ELECTRIC BLACK
(
RoHS
)
7
351-AM03018A364-E MACHINE SCREW M3*18 ELECTRIC BLACK
(
RoHS
)
2
351-HM03006A308-E MACHINE SCREW M3*6mm ELECTRIC BLACK
(
RoHS
)
1
351-HM04010A217-E M4*10 MACHINE SCREW ELECTRIC BLACK
(
RoHS
)
4
352-AM03008D040-E ￠3*8 BPING SCREW ELECTRIC BLACK
(
RoHS
)
2
352-AM03008D041-E ￠3*8 BBPING SCREW PLATTING NICKEL
(
RoHS
)
2
352-AM03010D065-E ￠3*10 PBPING SCREWPLATTING NICKEL
(
RoHS
)
1
352-BM03010D064-E ￠3*10 BBPING SCREWELECTRIC BLACK
(
RoHS
)
2
355-P07049-E WASHER 7.2*12*0.5t COLOR
(
RoHS
)
2
361-FE-00002-0LAE HOLDER 90*70*15mm
(
RoHS
)
1
361-FE-05016-0LAE SECC HOLDER 36*12.5*8.5
(
RoHS
)
1
362-FE-00013-0LAE PCB HOLDER L TYPE t=1.6mmS.P.C.C 89*9*1.6T
(
RoHS
)
1
21
LS120P

JBL LS Series Specifications

General

Type	Powered Subwoofer
Enclosure Type	Bass Reflex
Woofer Size	12 inch
Amplifier Power	300W RMS
Inputs	LFE
