Section 5: LSR2310SP Powered Studio Subwoofer
Front View Back View
Features
1. Low Frequency Transducer “Woofer” – Reproduces low frequency signals.
2. Protective Grille – Protects the woofer when the subwoofer is placed in a location where the woofer
could be damaged by feet or objects.
3. Power Indicator – Illuminates when power is connected and the Power Switch is set to ON.
4. Feet – Elevates the Subwoofer to prevent acoustic coupling with the oor and prevent scratching
of the enclosure.
5. Low Frequency Port – Works in conjunction with the low frequency transducer
to provide accurate low frequency performance and air ow to cool the internal electronics.
6. Input Panel - Includes input connectors, power connector and user controls.
5
6
2
1
4
3
