MPS1000 Electrical parts List
Part Number Description Qty Reference Designator
Main/Power PCB
Resistors
110-14100j26-e Resistor 10Ω 1/4W ±5% CF 26mm (RoHS) 2 R500,R615,
116-142201j26x-e metal oxide film Resistor 2.2K 1/4W ±5% MO 26mm (RoHS) 2 R532,R534,
118-08050000j-e SMD Resistor 0805 0Ω ±5% (ROHS) 5 C10,C15,C18,C22,R280,
118-08051001f-e SMD Resistor 0805 1K 1% (RoHS) 2 R541,R542,
118-08051001j-e SMD Resistor 0805 1/10W 1K ±5% (RoHS) 12
R406,R407,R410,R411,R552,R553,R55
6,R557,R560,R502,R519,R629,
118-08051002j-e SMD Resistor 10K 0805 1/10W 5% (RoHS) 20
R40,R42,R285,R417,R418,R445,R554,
R507,R508,R511,R540,R611,R612,R61
6,R621,R622,R623,R626,R627,R625,
118-08051003j-e SMD Resistor 100K 0805 1/10W 5% (RoHS) 9
R38,R45,R49,R50,R416,R294,R517,R6
18, R624,
118-08051004j-e SMD Resistor 1M 0805 1/10W 5%(RoHS) 2 R415,R447,
118-080510r0j-e SMD Resistor 0805 10ohm 5% (RoHS) 5 R41,R43,R521,R523,R613,
118-08051132f-e SMD Resistor 0805 11.3K 1% (RoHS) 1 R512,
118-08051202j-e SMD Resistor 12K 0805 1/10W 5% (RoHS) 2 R234,R513,
118-08051501j-e SMD Resistor 0805 1.5K 5% (RoHS) 1 R550,
118-08051503j-e SMD Resistor 150K 0805 1/10W 5% (RoHS) 1 R80A,
118-08051802j-e SMD Resistor 18K 0805 1/10W 5% (RoHS) 1 R274,
118-08051803j-e SMD Resistor 180K 0805 5% (RoHS) 1 R237,
118-08052001f-e SMD Resistor 0.1W 1% 2K (RoHS) 1 R77C,
118-08052002j-e SMD Resistor 20K 0805 1/10W 5% (RoHS) 6 R5,R6,R23,R24,R563,R564,
118-08052200j-e SMD Resistor 220Ω 0805 1/10W 5% (RoHS) 1 R501,
118-08052201j-e SMD Resistor 2.2K 0805 1/10W 5% (RoHS) 2 R228,R515,
118-08052202j-e SMD Resistor 22K 0805 1/10W 5% (RoHS) 12
R9,R10,R11,R12,R17,R18,R21,R22,R2
54,R287,R403,R628,
118-08052702j-e SMD Resistor 0805 27K ±5% (RoHS) 2 R257,R273,
118-08052703j-e SMD Resistor 270K 0805 5% (RoHS) 2 R551,R548,
118-08053300j-e SMD Resistor 0805 330Ω 5% (RoHS) 2 R37,R46,
118-08053301j-e SMD Resistor 3.3K 1/10W 0805 5% (RoHS) 1 R446,
118-08053302j-e SMD Resistor 33K 0805 5% (RoHS) 2 R277,R614,
118-08053902j-e SMD Resistor 0805 39K 5% (RoHS) 1 R631,
118-08054301j-e SMD Resistor 0805 4.3K ±5% (RoHS) 1 R505
118-08054302j-e SMD Resistor 0805 43K 5% (ROHS) 1 R503,
118-08054700j-e SMD Resistor 0805 470Ω ±5% (RoHS) 3 R510,R522,R524,
118-08054701j-e SMD Resistor 4.7K 0805 1/10W 5% (RoHS) 7 R1,R2,R19,R20,R275,R276,R520,
118-08054702j-e SMD Resistor 47K 0805 1/10W 5% (RoHS) 4 R14A,R77A,R405,R414,
118-08054703j-e SMD Resistor 470K 0805 1/10W 5% (RoHS) 1 R278,
118-08055101j-e SMD Resistor 0805 5.1K 5% (RoHS) 1 R514,
118-08055102j-e SMD Resistor 0805 51K 5% (RoHS) 2 R39,R44,
118-08055600j-e SMD Resistor 0805 560Ω ±5% (RoHS) 2 R256,R286,
118-08055601j-e SMD Resistor 0805 5.6K 5% (RoHS) 2 R238,R518,
118-08056202j-e SMD Resistor 62K 0805 1/10W 5% (RoHS) 4 R27,R28,R29,R30,
118-08056800j-e SMD Resistor 0805 680Ω ±5%(RoHS) 2 R504,R509,
118-08056801j-e SMD Resistor 0805 6.8K ±5% (RoHS) 1 R516,
118-08057504j-e SMD Resistor 7.5M 0805 1/10W 5% (RoHS) 1 R293,
118-08057871f-e SMD Resistor 7.87K 0805 1/10W 1% (RoHS) 1 R279,
118-12060000f-e SMD Resistor 0Ω 1206 1% (RoHS) 2 C32,C33,
116-303300j5vx-e metal oxide film Resistor 330Ω 3W 5% 5mm (RoHS) 2 R531,R533,
116-3091r0j00x-e metal oxide film Resistor 91R 3W 5%long (RoHS) 1 R539,
116-30r100j00x-e oxide film Resistor 0.1Ω 3W ±5% long crus (RoHS) 4 R408,R409,R412,R413,
Capacitors
129-a104ja03-e disc Capacitor 0.1 100V ±5% MSC (RoHS) 2 C522,C524,
129-a105j633-e metallized Capacitor 1 F 63V ±5% MSC (RoHS) 1 C505,
130-3f104z503-e disc Capacitor 0.1 50V +80/-20% (RoHS) 1 C502,
132-104ja03-e mylar Capacitor 0.1 F 100V ±5% (RoHS) 4 C10A,C61,C537,C538,
