Part Number Description Qty Reference Designator
Main/Power PCB
135-3227m25-e electrolytic Capacitor 220 F 25V ±20% (RoHS) 1 C504,
135-3337m16-e electrolytic Capacitor 330 F 16V ±20% (RoHS) 2 C612,C622,
135-b227m35-e electrolytic Capacitor 220 F 35V ±20% 105℃ (RoHS) 1 C515,
141-b0101j50-e CAP CERAMIC/CHIP 100PF 50V CH J NPO 0805 (RoHS) 10
C11,C12,C17,C19,C21,C4,C214,C338,
C339,C253,
141-b0470j50-e SMD ceramic Capacitor 47pF 0805 NPO 50V (RoHS) 2 C3,C9,
141-b7102k50-e SMD ceramic Capacitor 0.001 F 50V X7R 0805 10% (RoHS) 2 C401,C402,
141-b7103k50-e SMD ceramic Capacitor 0.01 50V X7R 0805 (RoHS) 3 C252,C270,C271,
141-b7104ka0-e SMD Capacitor 100nF 100V X7R 10% 0805 (RoHS) 4 C537,C538,C522,C524,
141-b7332j50-e SMD ceramic Capacitor 0805 X7R 3300pF 5% (RoHS) 2 C24,C25,
141-b7392j50-e SMD ceramic Capacitor 0805 3900PF 50V X7R (RoHS) 1 C507,
141-b7472k50-e SMD Capacitor 0805 X7R 4700PF 10% 50V (RoHS) 2 C511,C624,
142-av226k16h-e SMD electrolytic Capacitor ±10% 22 16V (RoHS) 1 C508,
142-av226k16h-e SMD electrolytic Capacitor ±10% 22 16V (RoHS) 6 C1,C2,C20,C16,C264,C508,
142-sv106m25h-e SMD electrolytic Capacitor 10 25V 5mm (RoHS) 10
C7,C8,C13,C14,C28,C27,C52,C53,C27
3,C272,
142-sv475m25h-e SMD electrolytic Capacitor 4.7 25V 4mm 85C (RoHS) 2 C545,C546,
142-sv476m16h-e SMD electrolytic Capacitor 47 16V 5.5mmH (RoHS) 5 C251,C531,C532,C534,C536,
135-c158m35-e electrolytic Capacitor 1500 F 35V±20% 105℃ 13mm*25mm (RoHS) 2 C501,C513,
138-5228m801-e large aluminium electrolytic Capacitor 2200 F 80±20% ψ25*30 (RoHS) 2 C521,C523,
139-c108m35-e low leakage electrolytic Capacitor 1000 F 20% 35V (RoHS) 1 C529,
130-2f221md00-e ceramic Capacitor 220pF 250V ±20% long crus LS=10mm (RoHS) 1 C539,
132-123ja03-e
m
y
lar ca
p
acitor 0.12 F 100V ±5% TAP
(
RoHS
)
1 C68
132-332ja03-e mylar capacitor 0.0033 100V ±5% TAP (RoHS) 1 C64
Semiconductors
192-027c1815gr-e transistor 2SC1815GR TOSHIBA(RoHS) NPN 2 Q200,Q201,
192-153j111-e FET J111 FAIRCHILD TO-92 (RoHS) 1 Q417,
197-631n4148-e Diode 500mW 75V 1N4148 Panjit (RoHS) 1 D50,
199-65001503g-e zener Diode GDZJ15C500mW 15V 2% ROHM 52mm 1N5245B (RoH
S
2 Z501,Z502,
190-99pc817c-e IC PC817C(COSMO) (RoHS) Optocoupler 1 U501,
192-161tip31c-e Transistor TIP31C SGS (RoHS) NPN 1 Q531,
192-162tip32c-e Transistor TIP32C SGS (RoHS) PNP 1 Q532,
192-16360nf06-e Transistor STP60NF06 SGS FE (RoHS) MOSFET 4 Q508,Q509,Q510,Q511,
197-301604gd-e bridge rectifier SF1604G-D (RoHS) 2 D511,D514,
197-306a20-e bridge rectifier 6A 200V 6A20 (RoHS) 1 D500,
190-06m4560ms-e IC SMD NJM4560M SOP8 (RoHS) Dual Op-Amp 2 U1, 3,
190-13494cdrs-e IC TL494CDR SMD TI PWM 1 U500,
190-16tl074cds-e SMD IC TL074CD ST (RoHS) Quad Op-Amp 1 U203,
192-027c1815grs-e SMT Transistor MMBT1815 SOT-23 (RoHS) 12
Q510,Q503,Q513,Q514,Q516,Q517,
Q610,Q611,Q622,Q626,Q624,Q405,
192-091sc4672-e Transistor 2SC4672(MPT3) ROHM (RoHS) 1 Q612,
192-111t5551s-e Transistor ON NPN MMBT5551L SOT-2 SMD (RoHS) 1 Q403,
192-192b5401s-e SMD Transistor PMBT5401 SOT-23 NPN PHILIPS(RoHS) 2 Q402,Q404,
192-998a1015grs-e SMD transistor MMBT1015 CJ SOT-23(RoHS) 7
Q515,Q502,Q504,Q505,Q506,Q621,
Q623,
192-998b766s-e SMD transistor 2SB766 CJ SOT-89 (RoHS) 1 Q500,
197-03rls4148s-e SMD Diode RLS4148-TE11 ROHM (RoHS) 10
D202,D201,D401,D402,D403,D503,D55
0,D551,D611,D612,
199-15000624s-e SMD zener diode HZ6C2 RENESAS SOT-23(RoHS) 1 Z500,
Miscellaneous
122-14102m1600-e Inductor 1.0mH ψ1.6mm (RoHS) 1 L502,
122-14144m4180-e Inductor 0.14mH Ferrite Core 18AWG 20% short crus (RoHS) 1 T1,
150-r36231504-e ring transformer RT36-6T 28T (RoHS) 1 T500,
120-1000003-e Inductor 10W AI YT-C3104-005 1CRHW 354708LTB (RoHS) 7
B500,B501,B502,B503,B504,B506,B50
162-5002d003-e WIRE drop-out line 20mm mottle 3PIN MIDPIN shrink sleeve (RoHS) 2
162-5002d004-e WIRE drop-out line 20mm mottle 2PIN MIDPIN shrink sleeve (RoHS) 1
109-1ttc802j0-e temperature sensing Resistor TTC-802(JS) NTC long crus (RoHS) 1 TH500,
MPS1000 Subwoofer
