JBL MPS1000 - Page 13

Part Number Description Qty Reference Designator
Main/Power PCB
171- 833h1cc-e relay 833H-1C-C 12VDC (RoHS) 1 RL50,
175-1b09v01-e coupling 9PIN PITCH=2.0mm (RoHS) 1 M200,
175-1c12v01-e coupling 12PIN PITCH=2.5mm(RoHS) 1 P1,
175-1d02v01-e coupling 2PIN PITCH=3.96mm (RoHS) 1 M100,
175-9b40h02-e row pin 40PIN PITCH=2.0mm horizontal (RoHS) 2
176-trpcb1m4-e terminal (PCB foursquare PIN) PCB1M4 (RoHS) 2 P2,P3,
162-a060d007-e wire array 600mm mottle +rubber bung (RoHS) 1
193-201612tr-e ceramic insulation T0-220 16mm*12mm (RoHS) 3
236-AL-05001-0LAE aluminum bar layer (RoHS) 1
304-AL-05090-0VAE lower cover AL Φ235.3*32H silver 1
317-000-00037-0LA
E
earth terminal M3lug plate t=0.3 (RoHS) 2
351-AM03008A078-
E
M3*8 machine screw nikel (RoHS) 6
351-AM03016A097-
E
M3*16 machine screw (RoHS) 4
351-AM03022A958-
E
machine screw M3*22 (RoHS) 2
351-FM04006A220-
E
M4*6 machine screw nikel (RoHS) 2
355-P0306242-E M3spring shim ID3.2 OD5.6 T0.8 (RoHS) 6
355-P0407236-E M4spring shim ID4.2 OD7.0 T1.0 nikel (RoHS) 2
359-FB-00018-0RA
E
fiber washer outside 12￠*inside 3.8￠*1t
(
RoHS
)
2
361-FE-05000-0LBE ICtrave 69*12*4*1.5t (RoHS) 2
410-000-05924-E model paster PAP MPS1000 use 1
Class D amp PCB
(Replacment of entire module is recommended, part# 051-B05083C-E).
Resistors
118-12060000f-e SMD Resistor 0Ω 1206 1% (RoHS) 1 R1,
118-12061001j-e SMD Resistor 1.00K 1206 5% (RoHS) 1 R2,
118-12061002j-e SMD Resistor 10.0K 1206 5% (RoHS) 6 R25,R29,R30,R30B,R7,R9,
118-120610r0j-e SMD Resistor 10.0Ω 1206 5% (RoHS) 4 R20,R20B,R22,R23,
118-12062002j-e SMD Resistor 20.0K 1206 5% (RoHS) 1 R26,
118-12062201j-e SMD Resistor 2.20K 1206 5% (RoHS) 19
R6,R13,R16,R31,R33,R34,R35,R36,R3
7,R38,R39,R40,R41,R42,R43,R44,R45,
R46,R32,
118-12062204j-e SMD Resistor 2.20M 1206 5% (RoHS) 1 R4,
118-12062701j-e SMD Resistor 2.70K 1206 5% (RoHS) 1 R10,
118-12063000j-e SMD Resistor 300.0Ω 1206 5% (RoHS) 1 R24,
118-12063301j-e SMD Resistor 3.30K 1206 5% (RoHS) 4 R14,R15,R27,R28,
118-12063902j-e SMD Resistor 39.0K 1206 5% (RoHS) 1 R3,
118-12064700j-e SMD Resistor 470Ω 1206 5% (RoHS) 3 R8,R11,R21,
118-12064701j-e SMD Resistor 4.70K 1206 5% (RoHS) 2 R5,R12,
Capacitors
128-e106ma01-se non polarized electrolytic Capacitor 10 F 100V 20% (RoHS) 2 C16,C17,
132-104kb50-e mylar Capacitor 0.1 ±10% 250V long crus LS-10.mm MD (RoHS) 1 C20,
132-105kb50-e mylar Capacitor 1 F 250V ±10% long crus (RoHS) 1 C40,
141-c0101k50-e SMD ceramic Capacitor 100pF 50V 10% 1206 NP0 (RoHS) 1 C4,
141-c0220k50-e SMD ceramic Capacitor 22pF 50V 10% 1206 SMT NPO (RoHS) 1 C5,
141-c0561k50-e SMD ceramic Capacitor 560pF 50V 10% 1206 NPO (RoHS) 1 C6,
141-c5104m50-e SMD ceramic Capacitor 1206 Y5V 0.1 F 50V ±20% (RoHS) 8 C2,C3,C7,C8,C9,C10,C11,C15,
141-c7223k50-e SMD ceramic Capacitor 0.022 F 50V 10% 1206 X7R (RoHS) 1 C13,
141-d7104kb5-e SMD ceramic Capacitor 0.1 F 250V 10% 1210 X7R (RoHS) 4 C12,C14,C18,C19,
Semiconductors
192-232irf9640-e FET IRF9640 IR P-CH TO220 (RoHS) 2 Q10,Q10B,
192-233f640n-e Transistor IRF640N INTERNATIONAL (RoHS) 1 Q11,
190-16tl072dts-e SMD I.C. TL072CDT SGS THOMSON (RoHS) Dual Op-Amp 1 IC1,
192-09124126qs-e SMD Transistor 2SC2412K-T146Q/R ROHM (RoHS) 2 Q1,Q4,
192-09139066rs-e SMD Transistor 2SC3906K-T146R ROHM (RoHS) 2 Q2,Q8,
192-091sc4672-e Transistor 2SC4672(MPT3) ROHM (RoHS) NPN 1 Q5B,
MPS1000 Subwoofer
