Part Number Description Qty Reference Designator
Class D amp PCB
(Replacment of entire module is recommended, part# 051-B05083C-E).
192-09210376qs-e SMD Transistor 2SA1037K-T146Q/R ROHM (RoHS) 2 Q7,Q9,
192-09215146rs-e SMD Transistor 2SA1514K-T146R ROHM (RoHS) 1 Q3,
192-1582n5401-e Transistor FSC 2N5401 AI-PNP 350V 500mA TO-92 (RoHS) 1 Q6B,
197-03rls4148s-e SMD Diode RLS4148-TE11 ROHM (RoHS) 8 D1,D2,D3,D4,D5,D5B,D6,D20,
199-15000563s-e SMD ZENER 5.6V 5% PHILIPS BZX84-C5V6 (RoHS) 2 Z1,Z2,
199-1500120s-e SMD ZENER 12V 5% PHILIPS BZX84-C12 (RoHS) 4 Z3,Z4,Z5,Z6,
Miscellaneous
122-13151k0190-e CHOKE SA-500-280 (PT1601B*151MAA) (RoHS) 1 L1,
122-14300k4-e Ferrite core LD1215*300K ±10% short crus (RoHS) 1 L2,
Tone Control PCB
Resistors
118-08051001j-e SMD Resistor 0805 1/10W 1K ±5% (RoHS) 5 R200,R219,R222,R233,R264,
118-08051002j-e SMD Resistor 10K 0805 1/10W 5% (RoHS) 3 R229,R261,R262,
118-08051202j-e SMD Resistor 12K 0805 1/10W 5%(RoHS) 1 R227,
118-08051500j-e SMD Resistor 0805 150Ω 5% (RoHS) 1 R202,
118-08051502j-e SMD Resistor 0805 15k 5% (RoHS) 1 R218,
118-08052201j-e SMD Resistor 2.2K 0805 1/10W 5% (RoHS) 4 R255,R258,R259,R260,
118-08052202j-e SMD Resistor 22K 0805 1/10W 5% (RoHS) 2 R240,R241,
118-08052402j-e SMD Resistor 0805 24K 5% (RoHS) 1 R225,
118-08053601f-e SMD Resistor 3.6K 0805 1/10W 1% (RoHS) 1 R263,
118-08053901j-e SMD Resistor 0805 3.9K 5% (RoHS) 1 R224,
118-08053902j-e SMD Resistor 0805 39K 5% (RoHS) 1 R223,
118-08054701j-e SMD Resistor 4.7K 0805 1/10W 5% (RoHS) 1 R221,
118-08054702j-e SMD Resistor 47K 0805 1/10W 5% (RoHS) 2 R251,R253,
118-08054703j-e SMD Resistor 470K 0805 1/10W 5% (RoHS) 1 R220,
118-08056201j-e SMD Resistor 0805 6.2K ±5% (RoHS) 2 R250,R252,
115-v503b211-e
variable Resistor 2 gang 50KB RV112BF-40-8.5S-B50K (RoHS)
GAIN, CROSSOVER, BOOST
3 VR201,VR202,VR203,
Capacitors
141-b0101j50-e CAP CERAMIC/CHIP 100PF 50V CHJ NPO 0805 (RoHS) 3 C242,C284,C285,
141-b5104m50-e SMD ceramic Capacitor 0805 Y5V 0.1uF 50V ±20% (RoHS) 8
C274,C235,C229,C231,C233,C234,C23
9,C240,
141-b7102j50-e SMD ceramic Capacitor 0805 X7R 1nF 50V 5% (RoHS) 1 C280,
141-b7103k50-e SMD ceramic Capacitor 0.01U 50V X7R 0805 (RoHS) 1 C217,
141-b7104j50-e CAP CHIP 100NF 50.0V X7R K 0805 (RoHS) 1 C211,
141-b7153k50-e SMD Capacitor 0805 X7R 15nF 10% 50V (RoHS) 1 C265,
141-b7224k16-e SMD ceramic Capacitor 0.22U 16V 0805 X7R (RoHS) 5 C215,C260,C261,C262,C263,
141-b7274k25-e SMD ceramic Capacitor 0.27U 25V X7R 0805 (RoHS) 1 C210,
141-b7823j50-e SMD ceramic Capacitor 0.082U 50V X7R 0805 (RoHS) 1 C216,
142-sv106m25h-e SMDelectrolytic Capacitor 10U 25V 5mm (RoHS) 3 C23,C237,C238,
Semiconductors
190-06m4560ms-e IC SMD NJM4560M SOP8 (RoHS) 4 U200,U201,U204,U205,
195-10204ubd-e glow diode blue 204-10UBD (RoHS) 1 LD200
Miscellaneous
162-80429001-e spacer wire 9PIN 420mm WHT (RoHS) 1
166-a028a4bf-e two piece array speaker wire 280mm 18AWG T205*T110 (RoHS) 1
162-5006d005-e drop-out line red/black 2PIN 60mm UL1571 28AWG (RoHS) 1 for LED,
175-1b02v01-e coupling 2PIN PITCH=2.0mm (RoHS) 1 EL204BD,
175-1b09v01-e coupling 9PIN PITCH=2.0mm (RoHS) 1 W200,
180-sms6022p-e switch SLIDE SW MS-6022P EG2 (RoHS) PHASE 1 SW2,
MPS1000 Subwoofer
