JBL Partybox On-The-Go User Manual

JBL PartyBox on the Go Spare Part List
Part Number SAP Description Usage UoM Pos. No.
ABN100008-0306 M FRONT GRILL +FRONT CAB PARTYBOXGO 1 EA 1 ,2
ABN100008-0309 SKD P TRIM RINGPARTYBOXGO 1 EA 3
ABN115181-0001 GP SKD RGB LED PCB PARTYBOXGO 1 EA 4
AUIWD0013-GN01 SPK WOOFER DRIVER PARTYBOXGO 1 EA 5
AUICT0005-GN05 SPK TWEETER PARTYBOXGO 2 EA 6
ABN100008-0324 RUBBER FOOT PARTYBOXGO 1 EA 7
BPB100124-00AA BOTTOM COVER ABS PARTYBOXGO 1 EA 8
ABN100008-0307 SKD P BOTTOM SEALING COVERPARTYBOXGO 1 EA 9
ABN100008-0308 P WOOFER DRIVER FRAME PARTYBOXGO 1 EA 10
ABN100008-0311 P REAR SOUND HOUSING+RUBBER PARTYBOXGO 1 EA 11
ABN100008-0315 ANTENNA 650-928MHZ 360MM+IPEX PARTYBOXGO 1 EA 12
IVN100095-0001 MIC HOLDER R PARTYBOXGO 1 EA 13
LFA115189-0201 PCB MIC HOLDER R PARTYBOXGO 1 EA 14
BRT100087-0001 HANDLE SIDE RUBBER PARTYBOXGO 2 EA 15
BPT100129-00AA P HAND SIDE BKT ABS PARTYBOXGO 2 EA 16
BPV100183-00AA SIDE COVER R ABS PARTYBOXGO 1 EA 17
GST100098-0001 GP METAL BKT 1# SUS304 PARTYBOXGO 2 EA 18
GST100099-0001 METAL BKT 2# SUS304 PARTYBOXGO 2 EA 19
BPT110122-00AA HOOK RING RIGHT PARTYBOXGO 1 EA 20
GAL100602-0001 AL HOOK PIPE AL ALLOY 6063 PARTYBOXGO 2 EA 21
WMA100098-0001 P TUBE R ASM PARTYBOXGO 1 EA 22
ABN115190-0001 MAIN PCB PARTYBOXGO 1 EA 23
ABN115170-0001 POWER PCB CEM PARTYBOXGO 1 EA 24
ABN115183-0001 USB&MP3&AC JACK PCB ASS'YPARTYBOXGO 1 EA 25
LFA115184-0201 PCB COVER H PARTYBOXGO 1 EA 26
ABN100008-0312 P BATTERY COVR PARTYBOXGO 1 EA 27
FBY102072-0001 BATTERY PARTYBOXGO 1 EA 28
ABN100008-0305 REAR SEALING COVER PARTYBOXGO 1 EA 29
ABN100008-0323 RUBBER CONNECTOR PARTYBOXGO 1 EA 30
WMA100103-0001 REAR COVER ASSY PARTYBOXGO 1 EA 31
BPV100184-00AA SIDE COVER L ABS PARTYBOXGO 1 EA 32
LFA115188-0201 PCB MIC HOLDER L PARTYBOXGO 1 EA 33
IVN100094-0001 MIC HOLDER LPARTYBOXGO 1 EA 34
ABN100008-0314 ANTENNA 650-928MHZ 510MM+IPEX PARTYBOXGO 1 EA 35
BPT100122-00AA HOOK RING LEFT TPE 94HB PARTYBOXGO 1 EA 36
ABN100148-0046 WIRELESS MIC PARTYBOXGO 1 EA 37
ABN115182-0001 GP SKD MIC&GUITAR JACK PCBA PARTYBOXGO 1 EA 38
BPT100121-00AA P MIC PCB BKT PARTYBOXGO 1 EA 39
ABN115201-0001 KEY PCB FR-4 PARTYBOXGO 1 EA 40
BRT100098-0001 RUBBER PAD T0.5MM PARTYBOXGO 1 EA 41
WMA100097-0001 TUBE L ASM PARTYBOXGO 1 EA 42
LFA115206-0201 5#PCB FFC 30PIN WIRE PARTYBOXGO 1 EA 43
GAL100604-0001 AL MAIN PCB BKT L AL ALLOY PARTYBOXGO 1 EA 44
LFA115204-0201 3# PCB LED WIRE PARTYBOXGO 1 EA 45

JBL Partybox On-The-Go Specifications

General

Wi-Fi	No
AUX in	Yes
Bluetooth range	10 m
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Product type	-
Product color	Black
Product design	Rectangle
Volume control	Rotary
Battery type	Built-in battery
Battery capacity	2500 mAh
Battery life (max)	6 h
AC adapter frequency	50/60 Hz
Battery recharge time	3.5 h
AC adapter input voltage	100 - 240 V
Power consumption (standby)	0.5 W
Frequency range	50 - 20000 Hz
RMS rated power	100 W
Signal-to-Noise Ratio (SNR)	80 dB
Cables included	AC
Quantity per pack	2 pc(s)
Package depth	314 mm
Package width	600 mm
Package height	367 mm
Package weight	10150 g
Woofer diameter (imperial)	5.25 \
Tweeter diameter (imperial)	1.75 \
Recommended usage	Universal

Weight and Dimensions

Depth	224 mm
Width	489 mm
Height	244.5 mm
Weight	7500 g
