13
SYSTEM SPECIFICATIONS
System Type:
Self powered 12", two-way, bass-reflex
Frequency Range (-10 dB):
46 Hz - 20 kHz (EQ in main position) / 46 Hz - 20 kHz
60 Hz - 20 kHz (EQ in monitor position) / 58 Hz - 20 kHz
Frequency Response (±3 dB):
76 Hz - 20 kHz (EQ in main position) / 55 Hz - 20 kHz
90 Hz - 20 kHz (EQ in monitor position) / 90 Hz - 20 kHz
Coverage Pattern:
70º x 70º nominal
Directivity Index (DI):
10.2 dB
Directivity Factor (Q):
10.8
Crossover Modes:
DSP controlled 48 dB filter slope
Crossover Frequency:
1.6 kHz
System Power Rating:
500 W continuous, 1000 W peak
LF Power amp:
Class-D, 400 Watt (continuous) at driver impedance
HF Power amp:
Class-D, 100 Watt (continuous) at driver impedance
Distortion:
Less than 0.1% at rated power
Maximum Peak Output:
133 dB
Signal indicators:
Overload*: Red LED indicates input overload condition
Signal: Green LED indicates signal present
Input sensitivity range:
Mic position: -25 dBu to 0 dBu / -26 dBu to -8 dBu **
Line position: +10 dBu to +28 dBu / 0 dB to +18 dBu **
Input Impedance:
64 K Ohms (balanced), 32 K Ohms (unbalanced)
EQ:
Presets for use in Main and Monitor position
LF Driver:
1 x JBL 262F 380 mm (12 in) Differential Drive
®
woofer
HF Driver:
1 x JBL 2408H 37.5 mm (1.5 in) annular polymer diaphragm,
neodymium compression driver
Enclosure:
Trapezoidal, 18 mm, plywood
Suspension/ Mounting: PRX512M:
PRX512Mi:
Dual 36 mm pole socket
Dual 36 mm pole socket, 8 x M10 Suspension Points and
1 x M10 Pull-Back Point
Transport:
Integrated handle with backing cup
Finish:
Anthracite DuraFlex™ finish
Grille:
Powder coated, Anthracite, 18 gauge perforated steel
with acoustical transparent black foam backing.
Input Connectors:
Balanced XLR / 1/4 inch combo jack with XLR loop through
Dimensions (H x W x D):
639 mm x 384 mm x 363 mm
(25.2 in x 15.1 in x 14.3 in)
Net Weight:
18 kg (40 lb)
PRX512M / PRX512Mi
* PRX512Mi, Limiter: Red LED indicates limiter in operation
**PRX512Mi
