4. High-Pass
-Set up Set Generator at 100mV@at 100Hz
Signal to Low level input
Measure voltage at high-pass output
-Voltage measurement
Hi-Pass Pot Setting Output
CW 24mV
CCW 55mV
4. LED
With a 35mV input signal at a single Low level input, LED should change to green
See flow chart (following page) for detailed diagnostics.
