JBL SB130 - Spare Parts List

JBLSB130‐SparePartsList
Part Number SAP Description Usage UoM Pos. No.
101000303 HDMI CABLE SB110/130 1 EA
112000422 #IC TAS5825M(QFN32) SB110/130 2 EA U1&U5 on Main PCBA
104000283 POWER CORD AM SB110/130/160 1 EA
104000395 POWER CORD UK SB110/130/160 1 EA
104000394 POWER CORD EP/AS SB110/130/160/260 1 EA
104000365 POWER CORD KO SB110/130/160 1 EA
104000440 POWER CORD THA SB110/130/160 1 EA
104000443 POWER CORD AU SB110/130/160 1 EA
104000467 POWER CORD BR SB110/130/160 1 EA
104000437 POWER CORD IN SB110/130/160 1 EA
105001435 REMOTE CONTROL SB110/130/160 1 EA
112000051 #IC 74LVC2GU04GW SB110/130/160 1 EA U8 IN MAIN PCBA
112000308 IC EUP3482A (SOP8) SB110/130/160 1 EA U2 IN MAIN PCBA
112000336 IC AC6901AN (QFP-48) SB110/130/160 1 EA U3 IN MAIN PCBA
112000361 IC IA6003-33S89F (SOT-89) SB110/130/160 1 EA U1 IN MAIN PCBA
112000373 IC IA6006-ADJ (SOT23-5) SB110/130/160 1 EA U4 IN MAIN PCBA
112000406 IC W25Q16JVSSIQ(208MIL) SB110/130/160 1 EA U7 IN MAIN PCBA
112000429 #IC SPHE8109S-A (QFN-88) SB110/130/160 1 EA U9 IN MAIN PCBA
100002472 22# MAIN PCBA TO LEFT SPEAKER SB130 1 EA
100002473 22# MAIN PCBA TO RIGHT SPEAKER SB130 1 EA
101000182 CONNECTION WIRE SB130 1 EA M17
105001463 WOOD CASE SB130 1 EA M15
113000270 SUBWOOFER 4"4Ω30W SB130 1 EA M16
113000284 SPEAKER 2"8Ω20W SB130 2 EA M11
201001928 AIE TUBE SB130 1 EA M13
201004543 REAR CABINET SB130 1 EA M04
201004572 PC TUBE SB130 1 EA M03
403000612 POWER PCBA PW2014C-37(PW2014C) SB130 1 EA E01
404002447 MAIN PCBA SB130 1 EA E02
405001038 GIFT BOX IN SB130 1 SY
405001330 GIFT BOX UK SB130 1 SY
405001329 GIFT BOX AM SB130 1 SY
405001328 GIFT BOX AS SB130 1 SY
100002513 28# MAIN TO LED PCBA CABLE SB130/160 1 EA
100002381 28# KEY PCBA TO LED PCBA SB130/160 1 EA
100002471 20# MAIN TO POWER PCBA CABLE SB130/160 1 EA
112000330 IC WS4603E LOAD SWITCH SB130/160 1 EA U6 IN MAIN PCBA
200001944 IRON GRILL SB130/160 1 EA M07
200001957 COOLIING FIN SB130/160 1 EA M05
200001974 LOGO BRAND SB130/160 1 EA M14
201004569 LEFT SIDE COVER SB130/160 1 EA M01
201004570 RIGHT SIDE COVER SB130/160 1 EA M06
201004571 PLASTIC KEY CABINET SB130/160 1 EA M09
204000600 WOOFER SILICONE FOOT SB130/160 4 EA M23(160), M18(130)
204003556 SILICONE FOOT SB130/160 2 EA M13(160),M12(130)
204003560 INDICATOR FILTER SB130/160 1 EA M08
204003673 SILICONE BUTTON SB130/160 1 EA M10
402002230 SOUNDBAR KEY PCBA SB130/160 1 EA E04
404002445 SOUNDBAR LED PCBA SB130/160 1 EA E03
405001039 ACCESSORY KIT SB130/160 1 SY
