JBL SUB333 - Page 13

IC614-IC619 RCI4051-001 IC 16 PIN TC4051BFN CHIP 6
8 CH MULTIPLEXER
IC620 RCI6244-001 IC 42 PIN M62446FP ELECTRONIC 1
VOLUME CONTROL
IC624 RCI7404-001 IC 14 PIN TC74HC04AFN TOSHIBA 1
HEX INVERTER
IC625 RCI4052-001 IC 16 PIN TC4052BFN CHIP 1
4 CH MULTIPLEXER
IC626 RCI4227-001 IC 44 PIN CS4227 1
6 CH VOL CRYSTAL
IC627 RHI0256-001 IC 28 PIN EPROM IC 256K 120ns 1
Resistors
R601, R670, R674, QCF0152-000 CHIP RES. 0 OHM JUMP WIRE 6
R675, R676, R891 SMT TYPE
R673 QCF0152-473 CHIP RES. 47K OHM 1/10W 5% 1
SMT TYPE
R677, R736, R741, QCF0152-472 CHIP RES. 4.7K OHM 1/10W 5% 12
R746, R750, R756, SMT TYPE
R764, R809, R812,
R823, R888, R889
R678, R838, R882, QCF0152-223 CHIP RES. 22K OHM 1/10W 5% 5
R883, R884
R679, R683, R696, QCF0152-222 CHIP RES. 2.2K OHM 1/10W 5% 6
R698, R700, R707 SMT TYPE
R680, R695 QCF0152-122 CHIP RES. 1.2K OHM 1/10W 5% 2
SMT TYPE
R681, R684, R738, QCF0152-152 CHIP RES 1.5K OHM 1/10W 5% 8
R743, R748, R753, SMT TYPE
R758, R768
R682, R697, R699, QCF0152-162 CHIP RES. 1.6K OHM 1/10W 5% 5
R701, R848 SMT TYPE
R685, R686, R716, QCF0152-103 CHIP RES. 10K OHM 1/10W 5% 17
R717, R718, R719, SMT TYPE
R761, R788, R797,
R799, R813, R892,
R893, R894, R895,
R896, R897
R689 QAF0450-109 RESISTOR 1.0 OHM 1/4W 5% CF 1
R690 QAF0650-472 RESISTOR 4.7K OHM 1/6W 5% CF 1
R691, R709, R720, QCF0152-101 CHIP RES. 100 OHM 1/10W5% 29
R721, R722, R723, SMT TYPE
R785, R791, R798,
R802, R808, R821,
R825, R826, R835,
R849, R850, R851,
R852, R853, R855,
R856, R876, R877,
R878, R879, R880,
R881, R898
R692 QAF0650-102 RESISTOR 1K OHM 1/6W 5% CF 1
R693 QAF0650-681 RESISTOR 680 OHM 1/6W 5% CF 1
R694, R714, R715, QCF0152-390 CHIP RES. 39 OHM 1/10W 5% 5
R725, R726 SMT TYPE
R702 QCF0152-622 CHIP RES. 6.2K OHM 1/10W 5% 1
SMT TYPE
R703, R822, R827, QCF0152-822 CHIP RES. 8.2K OHM 1/10W 5% 12
R830, R833, R834, SMT TYPE
R836, R837, R842,
R843, R844, R845
R706, R740, R745, QCF0152-102 CHIP RES. 1K OHM 1/10W 5% 13
R751, R754, R762, SMT TYPE
R846, R854, R864,
R865, R868, R869,
R875
R708 QCF0152-202 CHIP RES. 2K OHM 1/10W 5% 1
SMT TYPE
R710, R711 QCF0152-203 CHIP RES. 20K OHM 1/10W 5% 2
SMT TYPE
R712, R713 QCF0152-682 CHIP RES. 6.8K OHM 1/10W 5% 2
SMT TYPE
R730 QCF0152-209 CHIP RES. 2 OHM 1/10W 5% 1
SMT TYPE
R735, R744, R749, QCF0152-512 CHIP RES. 5.1K OHM 1/10W 5% 6
R755, R759, R770 SMT TYPE
R737, R742, R747, QCF0152-562 CHIP RES. 5.6K OHM 1/10W 5% 6
R752, R757, R766 SMT TYPE
R801, R803, R804, QCF0152-224 CHIP RES. 220K OHM 1/10W 5% 6
R805, R806, R816 SMT TYPE
R807 QCF0152-301 CHIP RES. 300 OHM 1/10W 5% 1
SMT TYPE
R810 QCF0152-183 CHIP RES. 18K OHM 1/10W 5% 1
SMT TYPE
R815 QCF0152-433 CHIP RES. 43K OHM 1/10W 5% 1
0805 SMT TYPE
R817, R818, R819, QCF0152-362 CHIP RES. 3.6K OHM 1/10W 5% 5
R828, R829 SMT TYPE
R820 QCF0152-331 CHIP RES. 330 OHM 1/10W 5% 1
SMT TYPE
R847 QCF0152-392 CHIP RES. 3.9K OHM 1/10W 5% 1
SMT TYP
R862, R863, R866, QCF0152-272 CHIP RES. 2.7K OHM 1/10W 5% 7
R867, R873, R874, SMT TYPE
R887
R885, R886 QHM1050-151 RESISTOR 150OHM 1W 5% MF 2
Transistors
Q607 RCN1623-001 XISTR NPN SMT TYPE (2SC945) 1
HFE:200-400
Q608 RAP0733-001 XISTR PNP 2SA733Q,P NEC AI 1
Q609 RAN2001-001 XISTR NPN 2SC2001L NEC 1
Wires
CN604 4999A-519 CON/WRE AY 3 COND 150 mm 1
SHIELD WIRE
CN605 4999A-520 CON/WRE AY 3 COND 250 mm 1
SHIELD WIRE
CN606 4999A-522 CON/WRE AY 2 COND 260 mm 1
SHIELD WIRE
Miscellaneous
L606, L609 SAF0835-001 BEAD RH035083ST-Y7 3.5X8.3X0.76 2
L607, L610 SHC8121-101 CHOKE 100uh 2
L611 SRC0210-001 CHOKE TOKIN SBT-0210 1
COPPER SIDE XTP9777-023 TAPE HIGH TEMP TAPE NICHIBAN
IC601, IC626
L6, C884, L602, L603, SCF0805-600 CHIP BEAD 2012A601Y102B
L612, L613, L614, TEAM YOUNG
L615, L616D, L617,
L619-L649
13
Dolby Pro-Logic
Ò
Surround Processor/Amplifier/Subwoofer SUB333
SUB333 ELECTRICAL PARTS LIST Cont...
Ref.# Part # Description Qty. Ref.# Part # Description Qty.
