L604, L605 SAC7414-100 CHOKE 10uH AI 2
XL602 JQC6071-320 CRYSTAL 32.0000 MHz L=5.0 mm 1
APE0280-001 MAIN PCB ASSY
Connectors
CN201 CCN7879-030 CONNECTOR J.S.T. 2.0 mm PH 1
B10B-PH-K TOP SIZE
CN202 CCN7879-028 CONNECTOR J.S.T. 2.0 mm PH 1
B 8B-PH-K TOP SIZE
CN203 CCN7879-027 CONNECTOR J.S.T. 2.0 mm PH 1
B 7B-PH-K TOP SIZE
CN204 CCN7879-025 CONNECTOR J.S.T. 2.0 mm PH 1
B 5B-PH-K TOP SIZE
CN602 CCN2032-015 CONNECTOR TUC-P15P-B1 1
PITCH=2.0 mm TOP
CN603 CCN2032-007 CONNECTOR TUC-P7P-B1 1
PITCH=2.0 mm TOP
CN604 CCN7879-023 CONNECTOR J.S.T. 2.0 mm PH 1
B 3B-PH-K TOP SIZE
CN605 CCN1500-023 CONNECTOR B 3B-XH-A 3 PIN 1
POST BASE TOP P:2.5
CN606 CCN1500-018 CONNECTOR B 2B-XH-A 2 PIN 1
POST BASE TOP P:2.5
Capacitors
C101, C105 PRD4965-103 COND DISC 0.01uF 50V +80-20% 2
Z5V II D=6
C102, C106, C110, PRD3965-104 COND DISC 0.1uF 50V +80-20% 18
C111, C206, Y5V/Z5V
C211, C325,
C326, C336,
C337, C338,
C339, C403,
C404, C605,
C606, C637,
C638
C104, C108, C201, PRE3955-109 COND ELECT 1uF 50V 20% 85’C 8
C323, C324, C414,
C503, C504
C109, C305, C306, PRE3953-470 COND ELECT 47uF 25V 20% 85’C 10
C311, C312, C315,
C316, C319, C320,
C327
C202, C203 PRD1335-180 COND DISC 18pF 50V 5% 2
NP0 D=5
C204 PRE3955-478 COND ELECT 0.47uF 50V 20% 85’C 1
C205 PVE3951-222 COND ELECT 2200uF 10V 20% 1
C207, C210 PRE3952-470 COND ELECT 47uF 16V 20% 85’C 2
C208, C511 PRD4965-223 COND DISC 0.022uF 50V +80-20% 2
Z5V II D=7
C209 PRE3952-100 COND ELECT 10uF 16V 20% 85’C 1
C301, C302, C307, PRD3545-101 COND DISC 100pF 50V 10% Y5P 4
C308
C303, C304, C309, PRD1335-470 COND DISC 47pF 50V 5% NP0 9
C310, C328,
C331, C363,
C364, C719
C313, C314, C321, PRE3953-221 COND ELECT 220uF 25V 20% 85’C 10
C322, C356, C357,
C418, C419, C705,
C706
C317, C318 PRD1335-220 COND DISC 22pF 50V 5% 2
NP0 D=5
C332, C333, C401, PRM3737-822 COND MYLAR 0.0082uF 100V 5% 5
C601, C602
C334, C335, C402, PRD3545-221 COND DISC 220pF 50V 10% 5
C603, C604 Y5P II D=5C330
C340, C341, C342, PRM3737-273 COND MYLAR 0.027uF 100V 5% 10
C343, C405, C406,
C607, C608, C609,
C610
C344, C345, C346, PRM3737-472 COND MYLAR 0.0047uF 100V 5% 20
C347, C352, C353,
C354, C355, C407,
C408, C411, C412,
C611, C612, C613,
C614, C619, C620,
C621, C622
C348, C349, C410, PRM3737-222 COND MYLAR 0.0022uF 100V 5% 8
C413, C501, C502,
C617, C618
C350, C351, C409, PRD3545-201 COND DISC 200pF 50V 10% Y5P 5
C615, C616
C415, C507, C508 PRD1395-509 COND DISC 5pF 50V +-0.5 pF 3
NP0 D=5
C416, C505, C506 PRE3952-330 COND ELECT 33uF 16V 20% 85’C 3
C417, C509, C510, PRM3737-104 COND MYLAR 0.1uF 100V 5% 5
C723, C724
C512 PRE3951-100 COND ELECT 10uF 10V 20% 85’C 2
C513, C514, C515, PRE3955-101 COND ELECT 100uF 50V 20% 4
C516
C517 PRE3953-101 COND ELECT 100uF 25V 20% 85’C 1
C523, C524 PRE3954-470 COND ELECT 47uF 35V 20% 85’C 2
C525 PRE3952-471 COND ELECT 470uF 16V 20% 85’C 1
C526 PRE3955-229 COND ELECT 2.2uF 50V 20% 85’C 1
C527 PRE3953-100 COND ELECT 10uF 25V 20% 85’C 1
C720, C721 PRM3737-183 COND MYLAR 0.018uF 100V 5% 2
C722 PRM3737-303 COND MYLAR 0.03uF 100V 5% 1
C725 PRM3737-683 COND MYLAR 0.068uF 100V 5% 1
C726 PRM3737-123 COND MYLAR 0.012uF 100V 5% 1
Diodes
D201, D202, D203, RAD4148-001 DIODE SW 1N4148 22
D204, D206, D207,
D303, D304, D305,
D306, D307, D308,
D401, D402, D501,
D502, D503, D504,
D505, D506, D507,
D508
D205 RAD4001-001 RECTIFIER 1N4001 1A 35VRMS 1
ZD201 RAZ0859-070 DIODE ZENR 5.6-5.9V 0.5W 1
HITACHI HZ6B-2
ZD301 RAZ0859-059 DIODE ZENR 2.3-2.5V .5W 1
ZD501,ZD502 RAZ0859-093 DIODE ZENR 22.3-23.3V 0.5W 2
HITACHI HZ22-3
14
Dolby Pro-Logic
Ò
Surround Processor/Amplifier/Subwoofer SUB333
SUB333 ELECTRICAL PARTS LIST Cont...
Ref.# Part # Description Qty. Ref.# Part # Description Qty.
To Next Page
