Q276, Q277, Q278,
Q279, Q301, Q302,
Q402, Q503, Q504,
Q505, Q508, Q513
Q509 Q511 RAN2001-001 XISTR NPN 2SC2001L NEC 2
Q401, Q501, Q502 RAN2878-001 XISTR NPN 2SC2878-A (TE2,M) 3
Q506, Q510 RAP0733-001 XISTR PNP 2SA733Q,P NEC AI 2
Q265, Q266, Q270, RAP0952-001 XISTR PNP 2SA952 NEC 5
Q271, Q512
Miscellaneous
MAIN PCB-1 GSE0093-001 HEAT SINK BRACKET 1
HT946
MAIN PCB-1 GSE0253-001 BRACKET PCB BRACKET-R SECC 1
MAIN PCB-1 GSE0254-001 BRACKET PCB BRACKET-L SECC 1
PCB BKT TO H120301-306 SCREW T3.0x0.5pxL6.0 mm 7
MAIN PCB-7 PAN HEAD BLACK
CR201 JQC6070-419 CRYSTAL 4.194304 MHz HC-49/U 1
RL501, RL502 MRL2212-002 RELAY MI-SH-212LM 12V DC 2
44 mA GOOD SKY
L402, L501, L502 SHR6619-001 RF COIL 1uH MDEC T40818-08 3
P3 TO AC3 20565-060BB WIRE 22 GA 60 mm BLACK 4-4 1
CPB JW20 UL 1007 TOP COATED
P1-P1 20565-130BB WIRE 22 GA 130 mm BLACK 4-4 1
UL 1007 TOP COATED
P2 TO P2 20565-150BB WIRE 22 GA 150 mm BLACK 4-4 1
UL 1007 TOP COATED
P4 TO P4 20565-260BB WIRE 22 GA 260 mm BLACK 4-4 1
UL 1007 TOP COATED
RB904 4999A-512 CON/WRE AY 5 COND 400 mm #18 1
RB502 4999A-515 CON/WRE AY 7 COND 300 mm #18 1
RB301 4999A-517 CON/WRE AY 6 COND 280 mm 1
SHIELD WIRE
RB205 4999A-518 CON/WRE AY 3 COND 400 mm 1
SHIELD WIRE
RB506 4999A-521 CON/WRE AY 5 COND 200 mm 1
SHIELD WIRE
RB302 4999A-526 CON/WRE AY 5 COND 350 mm 1
SHIELD WIRE
RB601 4999A-542 CON/WRE AY 11 COND 70mm P=2.01
UL1007 #26 WHT/BLK
RB504 500351801B0 COND WIRE 5 COND 180 mm 1
BLACK
RB906 500393001B0 COND WIRE 9 COND 300 mm 1
BLACK 26 AWG PITCH=2.5 mm
APE0281-001 POWER AMP PCB ASSY
Connectors
CN501 CCN3962-006 CONNECTOR 6 PIN CL3962WVO 1
CN502 CCN3962-007 CONNECTOR 7 PIN CL3962WVO 1
PITCH=3.96 mm
CN503 CCN3962-004 CONNECTOR 4 PIN CL3962WVO 1
PITCH=3.96 mm
CN504, CN506 CCN1500-016 CONNECTOR B 5B-XH-A 5 PIN 2
POST BASE TOP P:2.5
CN505 CCN3962-002 CONNECTOR 2 PIN CL3962WVO 1
P=3 96mm POST BASE TOP
CN903 CCN3962-003 CONNECTOR 3 PIN CL3962WVO 1
Capacitors
C623, C624 PRM3737-222 COND MYLAR 0.0022uF 100V 5% 2
C625, C626 PRE3955-109 COND ELECT 1uF 50V 20% 85’C 2
C627, C628, C708, PRE3952-330 COND ELECT 33uF 16V 20% 85’C 4
C712
C629, C630, C709 PRD1395-509 COND DISC 5pF 50V +-0.5 pF 3
NP0 D=5
C631, C632, C717 PRM3737-104 COND MYLAR 0.1uF 100V 5% 3
C633, C634, C635, PRE3955-101 COND ELECT 100uF 50V 20% 85’C 6
C636, C710, C716 VENTED TYPE
C639 PRE3953-470 COND ELECT 47uF 25V 20% 85’C 1
C640 PRE3953-470 COND ELECT 47uF 25V 20% 85’C 1
C707 PRE3952-100 COND ELECT 10uF 16V 20% 85’C 1
C711 PRD3545-101 COND DISC 100pF 50V 10% Y5P 1
C713, C714 PRD3545-471 COND DISC 470pF 50V 10% 2
Y5P II D=5
C718 PRM3737-472 COND MYLAR 0.0047uF 100V 5% 1
C935, C936, C937, PRD4965-223 COND DISC 0.022 uF 50V 4
C938 +80-20% Z5V II D=7
C939, C940 PVE3956-222 COND ELECT 2200uF 63V 20% 2
Diodes
D601, D602, D603, RAD4148-001 DIODE SW 1N4148 7
D604, D701, D702,
D703
D915, D916, D917, RHD5404-001 RECTIFIER 1N5404 4
D918
ZD601, ZD602 RAZ0859-093 DIODE ZENR 22.3-23.3V 0.5W 2
HITACHI HZ22-3
Integrated Circuits
IC603 RHI0407-050 IC 15 PIN STK407-050 POWER IC 1
IC703 RHI4038-001 IC 15 PIN STK4038II POWER IC 1
Resistors
R631, R632, R722 QAF0650-102 RESISTOR 1K OHM 1/6W 5% CF 3
R633, R634, R651, QAF0650-104 RESISTOR 100K OHM 1/6W 5% CF 6
R652, R708, R721
R635, R636, R637, QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF 8
R638, R655,
R709, R710,
R724
R639, R640, R647, QAF0650-152 RESISTOR 1.5K OHM 1/6W 5% CF 9
R648, R653,
R654, R711,
R715, R719
R641, R642, R712 QAF0650-563 RESISTOR 56K OHM 1/6W 5% CF 3
R643, R644, R717 QAF0250-479 RESISTOR 4.7 OHM 1/2W 5% CF 3
R645, R646, R718 QVE3050-228 RESISTOR 0.22 OHM 3W 5% 3
CEMENT FIXED RADIAL
16
Dolby Pro-Logic
Ò
Surround Processor/Amplifier/Subwoofer SUB333
SUB333 ELECTRICAL PARTS LIST Cont...
Ref.# Part # Description Qty. Ref.# Part # Description Qty.
