R649, R650, R720 QAF0650-393 RESISTOR 39K OHM 1/6W 5% CF 3
R713 QAF0650-223 RESISTOR 22K OHM 1/6W 5% CF 1
R714, R716 QAF0450-101 RESISTOR 100 OHM 1/4W 5% CF 2
R723 QAF0450-330 RESISTOR 33 OHM 1/4W 5% CF 1
Transistors
Q601, Q602, Q701 RAN2878-001 XISTR NPN 2SC2878-A (TE2,M) 3
Q603, Q604, Q702 RAN0945-001 XISTR NPN 2SC945P NEC 3
Q605 RAP0952-001 XISTR PNP 2SA952 NEC 1
Q606, Q703 RAN2001-001 XISTR NPN 2SC2001L NEC 2
Miscellaneous
F906, F907 CFC2557-001 FUSE CLIP5D5X20FUSE 4
L601, L602, L701 SHR6619-001 RF COIL 1uH MDEC T40818-08 3
P2 TO P2 20565-081BB WIRE 22 GA 80mm BROWN 4-4 1
UL 1007 TOP COATED
P1 TO P1 20565-200BB WIRE 22GA 200 mm BLACK 4-4 1
UL 1007 TOP COATED 1
POWER PCB-1 GSE0256-001 BRACKET PCB BRACKET (R) SECC 1
POWER PCB-1 GSE0257-001 BRACKET PCB BRACKET (L) SECC 1
PCB BKT TO H120301-306 SCREW T3.0x0.5pxL6.0 mm 3
POWER PCB-3 PAN HEAD BLACK
PCB BKT TO H120302-306 SCREW M3.0x0.5PxL6.0 mm 1
POWER PCB-1 BLACK W/WASHER
RB905 4999A-513 CON/WRE AY 4 COND 250 mm #18 1
RB100 4999A-632 CON/WRE AY 4 COND 250 mm 1
GY-GY P:2.5/2 28AWG UL1533
RB102 50024AE1BMM COND WIRE 3 COND 150 mm 1
BROWN
RL701 MRL2212-002 RELAY MI-SH-212LM 12V DC 1
44 mA GOOD SKY
APE0282-021 CONNECTOR PCB ASSY
DC PCB-1 GSE0256-001 BRACKET PCB BRACKET (R)
SECC ESC333
DC PCB-1 GSE0257-001 BRACKET PCB BRACKET (L)
SECC ESC333
PCB BKT TO H120301-306 SCREW T3.0x0.5pxL6.0 mm 4
DC PCB-4 PAN HEAD BLACK
RB101 500331501B6 COND WIRE 3 COND 150 mm 1
APE0282-011 DC PCB ASSY
Connectors
CN901 CCN3962-006 CONNECTOR 6 PIN CL3962WVO 1
CN902 CCN3962-002 CONNECTOR 2 PIN CL3962WVO 1
96mm POST BASE TOP
CN904 CCN3962-005 CONNECTOR 5 PIN CL3962WVO 1
PITCH=3.96 mm
CN905 CCN3962-004 CONNECTOR 4 PIN CL3962WVO 1
PITCH=3.96 mm
CN906 CCN1500-033 CONNECTOR B 9B-XH-A 9 PIN 1
POST BASE TOP P:2.5
Capacitors
C901, C902, C903, PRD4965-223 COND DISC 0.022 uF 50V 13
C904, C909, +80-20% Z5V II D=7
C910, C911,
C912, C915,
C916, C917,
C918, C934
C906, C908 PVE3955-472 COND ELECT 4700uF 50V 20% 2
C913, C914 PVE3954-222 COND ELECT 2200uF 35V 20% 85’C 2
C919 PVE3953-222 COND ELECT 2200uF 25V 20% 1
C920, C922, C924, PRD3965-104 COND DISC 0.1uF 50V +80-20% 8
C925, C927, Y5V/Z5V
C929, C931,
C933
C921 PRE3953-220 COND ELECT 22uF 25V 20% 85’C 1
C923, C926 PRE3953-221 COND ELECT 220uF 25V 20% 85 2
C928 PRE3954-101 COND ELECT 100uF 35V 20% 85’C 1
C930, C932 PRE3952-101 COND ELECT 100uF 16V 20% 85’C 2
VENTED TYPE
Diodes
D901, D902, D903, RHD0600-400 RECTIFIER 6A 400V P600G 4
D904
D905, D906, D907, RAD4002-001 RECTIFIER 1N4002 9
D908, D909,
D910, D911,
D912, D913
ZD901 RAZ0859-067 DIODE ZENR 4.7-4.9V 0.5W 1
HITACHI HZ5B-2
Integrated Circuits
IC901 RHI7815-001 IC 3 PIN REGULATOR 15V 1A 1
IC902 RHI7915-001 IC 3 PIN 7915 -15V REGULATOR 1
IC903 RHI7906-001 IC 3 PIN 7906 -6V REGULATOR 1
IC904 RHI7806-001 IC 3 PIN MC7806ACT (5V2) 1
+6V REGULATOR
Resistors
R907 QAF0250-470 RESISTOR 47 OHM 1/2W 5% CF 1
R910 QAF0650-332 RESISTOR 3.3K OHM 1/6W 5% CF 1
R911 QAF0650-472 RESISTOR 4.7K OHM 1/6W 5% CF 1
R912 QAF0650-473 RESISTOR 47K OHM 1/6W 5% CF 1
R913 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF 1
R914 QAF0450-222 RESISTOR 2.2K OHM 1/4W 5% CF 1
Transistors
Q906 RAP0733-001 XISTR PNP 2SA733Q,P NEC AI 1
Miscellaneous
F901-F905 CFC2557-001 FUSE CLIP5D5X20FUSE 1
17
Dolby Pro-Logic
Ò
Surround Processor/Amplifier/Subwoofer SUB333
SUB333 ELECTRICAL PARTS LIST Cont...
Ref.# Part # Description Qty. Ref.# Part # Description Qty.
