JBL SUB333 - APE0282-021 CONNECTOR PCB ASSY; APE0362-001 AMP PLATE ASSEMBLY

APE0282-021 CONNECTOR PCB ASSY
Connectors
CN205, CN305 CCN1500-023 CONNECTOR B 3B-XH-A 3 PIN 2
POST BASE TOP P:2.5
CN301, CN303 CCN1500-024 CONNECTOR B 6B-XH-A 6 PIN 2
POST BASE TOP P:2.5
CN302, CN304 CCN1500-016 CONNECTOR B 5B-XH-A 5 PIN 2
POST BASE TOP P:2.5
Miscellaneous
TO TIN FOIL CSL6521-002 SOLDER LUG OD7.0xID3.5xT0.3 mm 1
NICKEL
PA TO SOLDER LUG 20565-160BB WIRE 22 GA 160 mm BLACK 4-4 1
UL 1007 TOP COATED
AFA0048-004 CONTROL PANEL ASSY
LEDs
LD203, LD226-LD233, KEG0402-001 LED 2x4 mm BRIGHT GREEN 17
LD236-LD243
LD204, LD205, LD206 KEG0525-001 LED 2.5x5mm BRIGHT GREEN 22
LD207, LD210,
LD211, LD212,
LD214-LD225,
LD234, LD235,
LD244
LD201, LD202, KER0052-003 LED 2x5 mm RED 523 4
LD208, LD209 ID/LD-A HIGH LIGHT
Resistors
R243, R244 QAF0650-391 RESISTOR 390 OHM 1/6W 5% CF 2
R242 QAF0650-471 RESISTOR 470 OHM 1/6W 5% CF 1
R245 QAF0650-122 RESISTOR 1.2K OHM 1/6W 5% CF 1
Wires
RB201 4999A-523 CON/WRE AY 10 COND 320 mm 1
PITCH=2.0 mm
RB202 4999A-524 CON/WRE AY 8 COND 300 mm 1
PITCH=2.0 mm
RB203 4999A-511 CON/WRE AY 7 COND 300 mm 1
PITCH=2.0 mm
RB204 4999A-525 CON/WRE AY 5 COND 300 mm 1
PITCH=2.0 mm
Miscellaneous
RB201, RB202 XTP9777-023 TAPE HIGH TEMP TAPE
(COPPER SIDE) NICHIBAN 241
TA201, TA202, TA203, MAT2029-001 AI TACT SW 5.0 mm 160 gf 5
TA204, TA205 ALPS SKHVBE3520
BNP0073-001 PVC PLATE 1
BPF5056-BA1 CNTL PANEL (DP6P 1083) 1
BPK5031-000 CNTL KNOB 1
CTRL PCB TO H101001-108 SCREW T3.0x1.27p-2RHXL8.mm 3
CTRL PANEL-3 PAN HEAD NICKEL
CONTROL PANEL IVE0085-001 EVA SPONGE L100 x W30 x 2
WIRE DRESSING-2 T2.0mm BACK W/ADHESIVE
CONTROL PANEL
BPH0054-000 LED HOLDER ESC333 1
APE0362-001 AMP PLATE ASSEMBLY
Miscellaneous
JACK ASSY-1 BPA0021-001 REAR COVER HI-PS ESC350 (JBL) 1
JACK ASSY-1 BRB0004-001 RUBBER BUS NR-3 1
0.0616 JACK ASSY-1
JACK ASSY-1 KSA1600-001 FUSE 6A 125V SLOW 5x20 mm UL
JACK ASSY-2 BRB0003-001 RUBBER BUS NR-3 1
GSE0255-001 JACK PLATE SECC 120V
ESC333 (JBL)
BRB0005-001 RUBBER BUS NR-3
0.0305 SW RACKER
BRF0007-001 RUBBER BLACK 1
0.0800 AC CORD
DBU0002-001 BUSHING AC LINE BUSHING 1
PIN GOOD 4RF-5
DFH1229-001 FUSE HOLDR FUSE HOLDER 1
FH-B02 10A; DIA 5.2x20
0.5576 COND SAFETY-2
LIMITED PCB TO DSS0002-006 SPACER OD5.0xID3.1xH5.0 mm 2
REAR COVER &
CON PCB-2
POWER SW TO H060301-314 SCREW M3.0x0.5pxL14.0mm 2
JACK PLT-2 PAN HEAD BLACK
AC3 JACK TO JACK H101001-310 SCREW T3.0x1.27p-2RHxL10mm 9
PLT-2, JACK PCB PAN HEAD BLACK
TO JACK PLT-4 RCA JACK TO JACK PLT-1
CONNECTOR PCB H101002-114 SCREW T3.0x1.27p-2RHxL14mm 2
TO REAR COVER-2 W/WASHER NICKEL
LIMITED PCB TO
REAR COVER &
CON PCB-2
MSV0001-004 SW ROCKER 5A AC 250V TV-5 1
CHILY CAT NO.3051
0.7515 POWER SW-1
PLS3559-104 COND SAFTY 0.1uF 250V 20% 1
X2 CAP LEAD:25mm
SLF0201-013 BEAD FERIT BRH 17.5x12.7x9.5 1
CHILISIN
2559-080022 LINE LINK 370 mm BLACK VDE 1
ESC300 (JBL)
47455-D52 LINE CORD SPT-2 1980mm 1
POLARIZ BLK-UL DOUBLE INSULA
FUSE TO AC SW
5823-092BB WIRE 22 GA 90 mm RED 4-4 1
UL1617 DOUBLE INSULA
BUSHING-1, RUBBER-2
18
Dolby Pro-Logic
Ò
Surround Processor/Amplifier/Subwoofer SUB333
SUB333 ELECTRICAL PARTS LIST Cont...
Ref.# Part # Description Qty. Ref.# Part # Description Qty.
