JBL SUB333 - APE0284-001 JACK PCB ASSY

APE0284-001 JACK PCB ASSY
Capacitors
C358, C359, C360, PRD3545-470 COND DISC 47pF 50V 10% Y5P 4
C361
C362, C518, C519, PRD4965-223 COND DISC 0.022 uF 50V 6
C520, C521, C522 +80-20% Z5V II D=7
Jacks
JK201 CJM9380-028 JACK PHONE JYE TAI 3542-01-030 1
3.5 DIM
JK301 CJR6504-002 JACK RCA 4P RJ-1073-10-0300A 1
JYE TAI RED/WHITE
JK302 CTP0008-003 RCA JACK RJ-1081-05-0300A 1
1T GREEN
JK303 CJT0001-001 JACK TOSLINK JACK 1
2.8121 TO JACK PLATE
CSL6521-002 SOLDER LUG OD7.0xID3.5xT0.3 mm
NICKEL
JK501 CTM0005-001 TERMINAL JACK ASSY MOLEX 1
TYPE
Resistors
R372 QAF0650-472 RESISTOR 4.7K OHM 1/6W 5% CF1 1
L301 SAC7414-100 CHOKE 10uH AI 1
0.0260 GND TO SOLDER LUG
Wires
20565-081BB WIRE 22 GA 80mm BROWN 4-4
UL1007 TOP COATE
RB303 4999A-527 CON/WRE AY 6 COND 150 mm 1
SHIELD WIRE
RB304 4999A-528 CON/WRE AY 5 COND 150 mm 1
SHIELD WIRE
RB305 4999A-520 CON/WRE AY 3 COND 250 mm 1
SHIELD WIRE
RB501 4999A-516 CON/WRE AY 6 COND 300 mm #18 1
RB503 4999A-514 CON/WRE AY 4 COND 400 mm #18 1
APE0362-001 LIMITER PCB ASSY
Capacitors
C100 PRN3952-100 COND ELECT 10uF 16V 20% N.P. 1
C101 PRE3953-479 COND ELECT 4.7uF 25V 20% 85’C 1
C102, C104 PRE3953-101 COND ELECT 100uF 25V 20% 85’C 2
C103, C105 PRD3965-104 COND DISC 0.1uF 50V +80-20% 2
Y5V/Z5V
Connectors
CCN1500-015 CONNECTOR B48-XH-A 4 PIN POST BASE TOP 1
CCN1500-023 CONNECTOR B 3B-XH-A 3 PIN POST BASE TOP 2
Diodes
D100, D101 066X0070001 DIODE SW 1N914B 2
Integrated Circuit
IC100 RHI4558-001 IC 8 PIN JRC4558D JRC OP AMP 1
Resistors
R100, R103 QAF0650-223 RESISTOR 22K OHM 1/6W 5% CF 2
R101, R102 QAF0650-102 RESISTOR 1K OHM 1/6W 5% CF 2
R104, R105, R107,
R109, R110 QAF0650-103 RESISTOR 10K OHM 1/6W 5% CF 5
R106 QAF0650-105 RESISTOR 1.0M OHM 1/6W 5% CF 1
R108 QAF0650-474 RESISTOR 470K OHM 1/6W 5% CF 1
R111, R112 QAF0650-101 RESISTOR 100 OHM 1/6W 5% CF 2
R113 QAF0650-222 RESISTOR 2.2K OHM 1/6W 5% CF 1
Transistors
Q100, Q101 086X0113501 XISTR NPN 2N3904 MOTOROLA 2
Miscellaneous
JW100 AI20870-022 WIRE BARE 22 GA TINNED
19
Dolby Pro-Logic
Ò
Surround Processor/Amplifier/Subwoofer SUB333
SUB333 ELECTRICAL PARTS LIST Cont...
Ref.# Part # Description Qty. Ref.# Part # Description Qty.
