SDP-40HD Basic Operation
2-23
2CH STATUS
Provides information about 2-channel input sources. Features L and
R level meters.
See “Status Menu Parameter Descriptions” on page 27 for detailed information.
D STATUS
Provides information about Dolby Digital input sources. Features L,
C, R, SL, SR, SB, and LFE level meters.
See “Status Menu Parameter Descriptions” on page 27 for detailed information.
Parameter Possible Settings
INPUT Current input
MODE Current listening mode
INPUT TYPE ANLG, PCM
SAMPLE RATE 44.1kHz, 48kHz, 88.2kHz, 96kHz
2CH STATUS
INPUT
MODE
INPUT TYPE
SAMPLE RATE
dB
0
-6
-15
-30
-45
RL
S
Parameter Possible Settings
INPUT Current input
MODE Current listening mode
CHANNELS 3/2.1, 3/2, 3/1, 2/2, 2/1, 2/0, 1/0
BIT RATE 32 to 640kbps
EX ENCODED YES, NO
SAMPLE RATE 48kHz
2.0 ENCODING MATRIX, NONE
DIALOG OFFSET -27 to +4dB
MIX ROOM SMALL, LARGE
CENTER MIX LVL -3.0dB, -4.5dB, -6.0dB
SURR MIX LVL +0.0dB, -3.0dB, -6.0dB
D STATUS
INPUT
MODE
CHANNELS
BIT RATE
RL
EX ENCODED
>S
CSL
SR
LFE
dB
0
-6
-15
-30
-45
D STATUS
SAMPLE RATE
2.0 ENCODING
DIALOG OFFSET
MIX ROOM
CENTER MIX LVL
SURR MIX LVL
