Setup JBL
3-48
5 STEREO & 5.1 ANLG
Select the 5 STEREO & 5.1 ANLG option to configure the analog audio
input connectors as five stereo and one 5.1-channel connectors.
When 5 STEREO & 5.1 ANLG is selected:
• The 5.1-channel connector should only be used with
5.1-channel analog sources such as DVD-As and SACDs.
• The analog audio input connectors labeled 1, 2, 3, 4, and 5 are
configured as stereo connectors.
• The analog audio input connectors labeled 6, 7, and 8 are
configured as 5.1-channel connectors.
• Input sources that were assigned to the stereo connectors
labeled 6, 7, and 8 are reassigned to conform to the
5.1-channel configuration.
• The 5.1-channel input is sent to the Main Zone audio output
connectors as indicated in the table below.
8 STEREO INPUTS REAR PANEL CONFIG SETUP
REAR PANEL CONFIGSETUP 5 STEREO & 5.1 ANLG
Input Connector(s) Output Connector(s)
(L) & (R) Front L/R
(C) Center
(SUB) Subwoofer L/R & LFE
(LS) & (RS)
5 STEREO & 5.1 ANLG Side L/R & Rear L/R
To Next Page
