Venue Performance Series User’s Guide
VPSB7118DP
Specifications:
Frequency Response (+/-3dB): 39 Hz - 145 Hz
Frequency Range (-10dB): 29 Hz - 165 Hz
Max Peak Output: 129 dB SPL 1m
Transducer Section:
Low Frequency Section: JBL 2268G, 457 mm (18 in) dia., 76 mm (3 in) Dual
Coil, Differential Drive
®
, Direct Cooled
Bandpass Nominal Impedance: 4 ohms
System:
DP2 Internal Amplification Output (at nominal load): 3600 Watts Peak (1800 Watts Continuous)
DP1 Output Section: 1-Channel, Class I
Audio Input Connector: XLR with loop-through
Network Control Connector: Ethernet, RJ45 (DPAN, DPCN options)
Signal Processing: DSP based, resident in Input Module.
System Management: DSP based limiters for mechanical and thermal
protection
AC Power Operating Range: Auto Select 90-132VAC/216-264VAC, 50/60 Hz
AC Line Voltage: 50/60 Hz, Auto-Detect; 120V/240V (-15%, +10%)
AC Input Connector: Neutrik PowerCon (NAC 3MPA)
AC Loop-Thru: Neutrik PowerCon (NAC 3MPB)
AC Current Requirement: 6A per system at 120V, 3A per system at 240V
Enclosure:
Box Construction: 5/8 in. multi-ply exterior grade Baltic birch.
Internally braced. Black DuraFlex
™
finish
Suspension System: 8 standard air-cargo 3 in. track and 24 M10 fittings.
Grille: 14 Gauge Black, powder-coated perforated steel
with foam backing.
Dimensions (H x W x D): 514.4 x 701.8 x 812.8 mm
20.25 x 27.63 x 32 in.
Net Weight: 54 kg (129 lb)
VP SERIES SYSTEMS SPECIFICATIONS
VP7315/64DP
Specifications:
Frequency Response (+/-3dB): 43 Hz - 18 kHz
Frequency Range (-10dB): 34 Hz - 20 kHz
Coverage Pattern: 60° x 40° rotatable waveguide
Directivity Factor (Q): 15.85
Directivity Index (DI): 12 dB
Max Peak Output: 138 dB SPL 1m
Transducer Section:
Low Frequency Section: JBL 2265G, 381 mm (15 in) dia., 76 mm (3 in) Dual
Coil neodymium Differential Drive®, Direct Cooled
Bandpass Nominal Impedance: 4 ohms
Mid Frequency: JBL CMCD-82H, 200 mm (8 in) Dual Coil
Differential Drive
®
transducer
High Frequency: JBL2452H-SL, 100 mm (4 in) titanium damped
diaphragm, 1.5 in. exit.
Waveguide: JBL PT-K64-MHF
Bandpass Nominal Impedance: 8 ohms
System:
DP2 Internal Amplification Output (at nominal load): 2200 Watts Peak (1100 Watts Continuous)
DP2 Output (Continuous IEC shaped pink noise
into rated load impedance):
750LF/350HF Watts
DP2 Output Section: 2-Channel, Class I
Audio Input Connector: XLR with loop-through
Network Control Connector: Ethernet, RJ45 (DPAN, DPCN options)
Signal Processing: DSP based, resident in Input Module.
System Management: DSP based limiters for mechanical and thermal
protection
AC Power Operating Range: Auto Select 90-132VAC/216-264VAC, 50/60
AC Line Voltage: 50/60 Hz, Auto-Detect; 120V/240V (-15%, +10%)
AC Input Connector: Neutrik PowerCon
AC Loop-Thru: Neutrik PowerCon
AC Current Requirement: 6A per system at 120V, 3A per system at 240V
Enclosure:
Box Construction: 5/8 in. multi-ply exterior grade Baltic birch.
Internally braced. Black DuraFlex
™
finish.
Suspension System: 6 standard air-cargo 3 in. track and 12 M10 fittings.
Grille: 14 Gauge Black, powder-coated perforated steel
with foam backing.
Dimensions (H x W x D): 914.4 x 528.3 x 624.8 mm
36 x 20.8 x 24.6 in.
Net Weight: 44 kg (97 lb)
