11) NETWORK 100MB ACTIVITY
a) The Activity LED indicates data activity on the network line.
12) NETWORK 100MB LINK
a) The LINK LED indicates that the data is at 100 Megabits.
13) DATA
a) Yellow LED Flashes for received data packet addressed to this DPAN device.
CONNECTORS
8) AUDIO IN
a) F-XLR Active 20K Ohm Balanced, 10K Ohm Unbalanced.
b) Pin 2 Hot (Positive voltage produces outward cone motion of L.F. Transducers).
9) AUDIO OUT
a) M-XLR Passive Audio Pass-through.
b) Pin 2 Hot (Positive voltage produces outward cone motion of L.F. Transducers).
10) HiQnet 100MB NETWORK Connector
a) The network connector is a standard RJ-45 connector that allows the DPAN to connect to an Ethernet network.
Connection is made using a standard Category 5 cable to a network switch port.
MAC ADDRESS WINDOW
14) The MAC address is a unique 12 digit hexadecimal hardware address assigned to every network device by
the manufacturer and is not changeable by the user. This unique physical address enables each device on the
network to identify and communicate directly with other devices connected to the network.
