SPECIFICATIONS
VRX928LA - 8", Two-way, Llne-array Speaker
System Type: 8" two way, line array loudspeaker system
Frequency Range (-10 dB): 70Hz -20kHz
Frequency Response (±3 dB): 87Hz - 19kHz
Coverage Pattern: 100º x 15º nominal (horizontal x vertical), single unit
Crossover Modes: Bi-amp / passive, externally switch-able
Crossover Frequency: 2.0 KHz
Power Rating
1
: 400 W / 800 W / 1600W
(Continuous / Program / Peak) Bi-amp LF: 400 W / 800 W / 1600W
Bi-amp HF: 30 W / 60 W / 120 W (two drivers)
System Maximum SPL
2
: 122dB SPL (passive mode)
LF: 122 dB
HF: 128 dB
System Sensitivity (1 W @ 1m) 90 dB SPL (passive mode)
LF: 90 dB
HF: 108 dB
LF Driver: 1 x JBL 2168H-1, 200 mm (8 in) Differential Drive
®
woofer
HF Driver: 2 x JBL 2414H, 25 mm (1.0 in) neodymium compression driver
Nominal Impedance: Passive: 8 Ohms
Bi-amp LF: 8 Ohms
Bi-amp HF: 16 Ohms
Active Tunings: Tunings available at www.jblpro.com
Enclosure: 15 mm - 25 mm, multi ply birch plywood
Suspension / Mounting: Dual 36mm pole socket included. Suspension requires optional
VRX-SMAF line array frame kit or 10 mm eyebolt.
Transport: Integrated handle with backing cup
Finish: Black DuraFlex™ finish
Grille: Powder coated, black, 18 gauge perforated steel with acoustical transparent black foam backing.
Input Connectors: 2x Neutrik
®
Speakon NL-4
Dimensions (H x W x D): 230 mm x 419 mm x 267 mm (9 in x 16.5 in x 10.5 in)
Net Weight: 12.7 kg (28 lb.)
Optional Accessories: VRX-SMAF: Suspension array frame
SS2-BK: Tripod speaker stand
Eyebolt Kit (Part # 229-00009-01)
Functional Block Diagram
1 IEC filtered noise with 6 dB crest factor, 2 hours.
2 Calculated, based on power rating and sensitivity.
6
