JBL VRX918SP User Manual

3
PATENTS
VRX series products are manufactured and sold under U.S. patents 5,748,760; 6,112,847; 6,394,223; 6,847,726;
6,774,510; D483,743; and 6,768,806.
CONTENTS
Section 1. Safety Instructions 4
JBL DrivePack
®
Declaration of Conformity 6
Section 2. Before You Begin 7
Section 3. Introduction to The VRX932LAP 8
Section 4. Introduction to The VRX918SP 10
Section 5. JBL DrivePack
®
Technology 12
VRX932LAP Input Panel 15
VRX918SP Input Panel 17
Amplitude Shading 19
Section 6. Deploying The System 21
Section 7. Suspension Safety Warnings! 23
Section 8. Introduction to The VRX-AF 26
JBL Warranty and Information 27
VRX_Powered_UsersGuid012808 copy 3.qxp 1/30/08 4:52 PM Page 3

JBL VRX918SP Specifications

General

Power Rating	1500 W Peak
Driver	18 inch Differential Drive woofer
Input Connectors	XLR, 1/4"
Output Connectors	XLR with loop-through
Enclosure Material	Birch plywood
Dimensions	508 mm x 597 mm x 749 mm (H x W x D)
Type	Self-powered subwoofer system
