VT X A12 | User Manual
26
12 - SPECIFICATIONS
System
Frequency Range (-10 dB):
46 Hz - 19 kHz (Preset: VTX A12)
Coverage Pattern (-6dB)
Horizontal:
Vertical:
90 degrees nominal (250Hz - 18kHz)
Varies with array size and configuration
System Input Power Rating
1
LF :
MF :
HF :
2 x 800W Continuous (IEC /100 hour)
400W Continuous (IEC /100 hour)
150W Continuous (IEC /100 hour)
Maximum Peak Output²:
146dB (Preset: VTX A12)
System Processing:
Crown Audio I-Tech HD Series
Crown Audio I-Tech 4x3500HD
System Impedance
LF :
MF :
HF :
2 x 8 ohms
8 ohms
8 ohms
Transducers
Low Frequency : 2 x JBL 2264H, 12in diameter, dual 3in diameter voice coil, Neodymium Differential Drive
Mid Frequency : 4 x JBL 2165H, 5.5in diameter, dual 2in diameter voice coil, Neodymium Differential Drive
High Frequency : 3 x JBL 2423K, 2in diameter annular diaphragm, 2in diameter voice coil, Neodymium Magnet
Enclosure
Construction : 18mm and 15mm ,11-ply Finnish birch plywood, Black DuraFlex
TM
finish, integral recessed handles
IP Rating
3
: IP55 EN (60529)
UV Rating : 6 (ISO105-B01)
Suspension : Captive suspension plates, quick-release pins, auto-locking mechanism for setting angles
Inter-enclosure Angle : 0.25, 0.5, 1, 1.5, 2, 2.5, 3, 4, 6, 8, 10
Grill : Powder coated 14-guage hex-perforated steel with acoustically transparent black cloth backing
Connectors
Type :
Pin Assignments :
Neutrik® SpeakON® NL-8 (2x)
Pins 1 ± (LF), Pins 2 ± (LF),
Pins 3 ± (MF), Pins 4 ± (HF)
Dimensions (H x W x D) : 330.2mm x 1.118mm x 495.3mm
13.0in x 44.0in x 19.5in
Net Weight : 60.8 kg (134.0 lbs)
Footnotes:
1: IEC Standard: IEC shaped noise with 6dB crest factor based on nominal impedance and a duration of 100 hours
2: Peak, unweighted SPL, measured under full-space conditions at 1 meter using broadband pink noise with a 12dB crest factor and specified preset
3: Front face at 0 degree or greater down angle to allow the cabinet to drain water. Suspension components fully weather rated for indoor or covered outdoor conditions where humidity is nominally under 50% and not
local to bodies of corrosive materials
JBL continually engages in research related to product improvement. Some materials, production methods and design refinements are introduced into existing products without notice as a routine expression of that
philosophy. For this reason, any current JBL product may differ in some respect from its published description, but will always equal or exceed the original design specifications unless otherwise stated.
