3 - 2
Section B Body & Framework
9803/6410
Section B
3 - 2
Issue 1
Main Body
Weights (cont’d)
Weight
Part Name JS130 JS160
1 Travel motor 166 kg (366 lb) 225 kg (496 lb)
2 Drive sprocket 57 kg (126 lb) 56 kg (125 lb)
3 Idler wheel 70 kg (154 lb) 87 kg (192 lb)
4 Top roller assembly 13 kg (29 lb) 17 kg (37 lb)
5 Bottom roller assembly 26 kg (57 lb) 35 kg (77 lb)
6 600 mm grouser shoe assembly 841 kg (1854 lb) 1167 kg (2573 lb)
7 700 mm grouser shoe assembly 995 kg (2194 lb) 1377 kg (3036 lb)
8 Slew mechanism 101 kg (223 lb) 197 kg (434 lb)
9 Slew ring bearing 170 kg (375 lb) 242 kg (534 lb)
10 Counterweight 2540 kg (5601 lb) 2930 kg (6461 lb)
11 Engine 387 kg (853 lb) 354 kg (781 lb)
12 Radiator 64 kg (141 lb) 85 kg (187 lb)
13 Hydraulic pump 84 kg (185 lb) 83 kg (183 lb)
14 Fuel tank 85 kg (187 lb) 82 kg (181 lb)
15 Hydraulic tank 105 kg (232 lb) 95 kg (209 lb)
16 Control valve 111 kg (245 lb) 104 kg (229 lb)
17 Rotating coupling 27 kg (60 lb) 23 kg (51 lb)
18 Boom 744 kg (1641 lb) 947 kg (2088 lb)
19 Dipper 345 kg (761 lb) 450 kg (992 lb)
20 Boom ram 116 kg (256 lb) 169 kg (373 lb)
21 Dipper ram 160 kg (353 lb) 226 kg (498 lb)
22 Bucket ram 97 kg (214 lb) 122 kg (269 lb)
(Dry Weight)
