41 - 6
Assembly
1.
Mount the bushing (131) and 'O'-ring (122) on the casing
(101).
2.
Attach the port plate with hexagonal socket head bolts
(125) and seal washer (121) to the casing (101).
Note:
Align the plate so that the spring pins (126) enter the
holes in the casing.
Section E
Hydraulics
9803/6400
Section E
41 - 6
Issue 1
Remote Control Valve JS200/JS240
