Boom Ram (continued)
4. a. Remove the nuts, bolt and collar.
b. Push out the pin, using a bar and hammer.
5. Lower the Boom ram and place it on a stand.
6. Restrain the eye end of the Boom ram rod to the ram
cylinder, to prevent movement of the rod.
7. Release the Tank Pressure.
See Releasing the Tank Pressure.
74 - 2
Section E
Hydraulics
9803/6400
Section E
74 - 2
Issue 1
Hydraulic Rams
