jcb JS260 User Manual

3 - 2
Section B
Body & Framework
9803/6400
Section B
3 - 2
Issue 2*
Main Body
*
Position
Weight (kg)
Symbol
Name
JS200 JS200LC JS220 JS220LC
A Overall Mass 18700 19100 21475 22155
B Upper Mechanism 8340 9850
Includes counterweight and
slew ring bearing
C Counterweight 3710 5010
D Undercarriage (with grouser shoe) 6650 7080 7823 8503
E Shoe (600 mm grouser) (one side) 1270 1350 1388
F Machine Main Body 14990 15420 17673 18353
G Attachment 3659 3706 3802
H Boom (including ram) 2050
I Dipper (including ram and link) 974
J Bucket 682
Weights JS200, JS200LC, JS220, JS220LC
Machine fitted with 3 m boom, 600 mm grouser shoes, 0.7 m
3
bucket (JS200/220), 0.8 m
3
bucket (JS200LC/220LC).
*
Position
Weight (kg)
Symbol
Name
JS240 JS240LC JS260 JS260LC
A Overall Mass 22500 23100 24920 25790
B Upper Mechanism 9850 10785
Includes counterweight and
slew ring bearing
C Counterweight 4510 5500
D Undercarriage (with grouser shoe) 7950 8550 9399 10269
E Shoe (600 mm grouser) (one side) 1370 1480 1445
F Machine Main Body 17800 18400 20184 21054
G Attachment 4684 4736
H Boom (including ram) 2638
I Dipper (including ram and link) 1268
J Bucket 830
Weights JS240, JS240LC, JS260, JS260LC
Machine fitted with 3.1 m boom, 600 mm grouser shoes, 0.9 m
3
bucket (JS240/260), 1.0 m
3
bucket (JS240LC/260LC).
*
