3 - 3
Section B
Body & Framework
9803/6400
Section B
3 - 3
Issue 2*
Main Body
*
Weights JS200, JS200LC, JS220, JS220LC, JS240, JS240LC, JS260, JS260LC
*
Dry Weight (kg)
Part Name JS200/220 JS200LC/220LC JS240/260 JS240LC/260LC
1 Travel motor 270
2 Drive Sprocket 51
3 Take-up roller 88
4 Upper roller assembly 17
5 Lower roller assembly 37
6 500 mm grouser shoe assembly 1266 1348 1386 1485
7 600 mm grouser shoe assembly 1473 1569 1505 1633
8 700 mm grouser shoe assembly 1601 1706 1636 1775
9- - - - -
10 Slew mechanism 194 335
11 Slew ring 216 389
12 Counterweight 3710/5010 4510/5500
13 Engine 490 495
14 Radiator 106 145
15 Hydraulic pump 150
16 Fuel Tank 81
17 Sump Tank 127
18 Control valve 166
19 Rotary joint 31
20 Boom 1305 1747
21 Dipper 613 786
22 Bucket 682 830
23 Boom ram 179 211
24 Dipper ram 277 341
25 Bucket ram 148 215
To Next Page
