Routine Maintenance
Fuel System
144 144
9811/5700-7
Changing the Water Separator Pre Filter
1 Get access to the Water Separator and Engine Fuel
Filter. Refer to Water Separator and Engine Fuel
Filter, Introduction.
2 Drain and remove the water separator bowl C.
K
Draining the Water Separator and Engine Fuel
Filter ( T 143).
3 To remove the filter element A, release locking ring B
and discard element.
4 Fit new element and secure in position with locking
ring B.
5 Refit water separator bowl. Secure in position with
locking ring B. K
Draining the Water Separator and
Engine Fuel Filter ( T 143).
6 Make sure that the fuel electrical connector E is
correctly fitted. K
Fig 109. ( T 144)
Fig 109.
