Part No. 960-000192R_Rev. A © 2017 JCM American Corporation
4
Lecture Notes
GEN2U™ Printer JCM® Training Overview August, 2017
COMPONENT LOCATIONS
C
OMPONENT
N
AMES
Figure 2 illustrates the GEN2U Component Names and Locations.
Figure 2 GEN2U Printer Component Names
e
l
b
a
c
d
f
g
h
j
k
i
a) RS232/USB Coil Interface Cable
b) Coil Interface Cable Connector
c) Lid Latch
d) Copper Shield
e) Bezel LED Connector
f) Bottom Tray
g) Upper Lid
h) Feed Button
i) Status LEDs
j) Rubber Boot
k) USB Update Port
l) Paper Tray (300 Ticket)
