GEN5™ Printer
© 2017 JCM Global Corporation 18 Part No. 960-000194R_Rev. A
6. Open the Print Head Release Lever (Figure 13 a).
7. Clean the Print Head (Figure 13 b) using a Cleaning Swab.
a
b
Figure 12 Presenter Assembly
a
b
Figure 13 Print Head Release Lever/Print Head
Clean Print Head (b)
with Cleaning Swab
GEN5_FlipBookRevA_v15.fm Page 18 Friday, June 30, 2017 9:20 AM
