JCM TBV Series User Manual

Part No. 960-100941R_Rev. A © 2016 JCM American Corporation
29
Lecture Notes
TBV Transaction Based Validator JCM® Training Overview October, 2016
18 SDRAM Reading
SDRAM Reading and/or Writing was not properly completed.
[Solution] Check the following parts and Harnesses.
[Relative Parts] CPU Board
If the condition is not resolved, change the above related part and calibrate
the Unit.
19
EEPROM
Reading
EEPROM Reading is not properly completed.
[Solution] Check the following parts and Harnesses.
[Relative Parts] CPU Board
If the condition is not resolved, change the above related part and calibrate
the Unit.
20
EEPROM
Writing
EEPROM Writing is not properly completed.
[Solution] Check the following parts and Harnesses.
[Relative Parts] CPU Board
If the condition is not resolved, change the above related part and calibrate
the Unit.
21
Feed Motor
Over Current
While operating, the Feed Motor detected an Over Current condition.
[Solution] Check the following parts and Harnesses.
[Relative Parts] Feed Motor
If the condition is not resolved, change the above related part.
22
Stacker Motor
Over Current
While operating, the Stacker Motor detected an Over Current condition.
[Solution] Check the following parts and Harnesses.
[Relative Parts] Stacker Motor
If the condition is not resolved, change the above related part.
23
Feed Motor
Overheat
While operating, the Feed Motor detected an Overheat condition.
[Solution] Check the following parts and Harnesses. Clean the Unit.
[Relative Parts] Feed Motor
If the condition is not resolved, change the above related part.
24 Calibration
During Power Up, valid Calibration was not detected.
[Solution] Calibrate the Unit.
[Relative Parts] CPU Board
If the condition is not resolved, change the above related part and calibrate
the Unit.
Table 14 TBV Operational Error Codes (Continued)
LED Color
Flash
Sequence
Error Causes and Solutions
