October, 2016 JCM® Training Overview TBV Transaction Based Validator

Lecture Notes

Table 20 Sensor Flag Values

(Validation Sensor Calibration Error)

String Sensor Flag Value String Sensor Flag Value

dll_ore_ref

0000-0000-0000-0001

dl_ir_pen 0000-0000-0400-0000

dl_blu_ref 0000-0000-0000-0002 dc_irl_pen 0000-0000-0800-0000

dc_redl_ref 0000-0000-0000-0004 dr_ir_pen 0000-0000-1000-0000

dr_blu_ref 0000-0000-0000-0008 drr_nir_pen 0000-0000-2000-0000

drr_ore_ref 0000-0000-0000-0010 dll_ore_pen 0000-0000-4000-0000

dl_ir_ref 0000-0000-0000-0020 dl_nir_pen 0000-0000-8000-0000

dc_irl_ref 0000-0000-0000-0040 dc_irr_pen 0000-0001-0000-0000

dc_ir_ref 0000-0000-0000-0080 dr_nir_pen 0000-0002-0000-0000

dc_irr_ref 0000-0000-0000-0100 drr_ore_pen 0000-0004-0000-0000

dll_gre_ref 0000-0000-0000-0200 dll_gre_pen 0000-0008-0000-0000

dc_redr_ref 0000-0000-0000-0400 dl_ore_pen 0000-0010-0000-0000

drr_gre_ref 0000-0000-0000-0800 dc_redr_pen 0000-0020-0000-0000

ull_ore_ref 0000-0000-0000-1000 dr_ore_pen 0000-0040-0000-0000

ul_blu_ref 0000-0000-0000-2000 drr_gre_pen 0000-0080-0000-0000

uc_redl_ref 0000-0000-0000-4000 ull_ore_pen 0000-0100-0000-0000

ur_blu_ref 0000-0000-0000-8000 ul_blu_pen 0000-0200-0000-0000

urr_ore_ref 0000-0000-0001-0000 ur_blu_pen 0000-0400-0000-0000

uc_irl_ref 0000-0000-0002-0000 urr_ore_pen 0000-0800-0000-0000

uc_irr_ref 0000-0000-0004-0000 ull_nir_pen 0000-1000-0000-0000

ull_gre_ref 0000-0000-0008-0000 ul_ore_pen 0000-2000-0000-0000

ul_ir_ref 0000-0000-0010-0000 ur_ore_pen 0000-4000-0000-0000

uc_redr_ref 0000-0000-0020-0000 urr_nir_pen 0000-8000-0000-0000

ur_ir_ref 0000-0000-0040-0000 ull_ir_pen 0001-0000-0000-0000

urr_gre_ref 0000-0000-0080-0000 ul_ir_pen 0002-0000-0000-0000

dc_redl_pen 0000-0000-0100-0000 ur_ir_pen 0004-0000-0000-0000

dll_nir_pen 0000-0000-0200-0000 urr_ir_pen 0008-0000-0000-0000

JCM TBV Series User Manual

Questions and Answers:
