Now Adjusting
<scr 5>
(8) Press the ENTER key to start calibration. Repeat the steps (5) to (8) three to five times until screen 7
appears.
<scr 6>
Set White reference paper. Hit Enter Key.
Adjustment BAR Sensor
(7) When screen 6 appears, remove the black reference paper and insert the white calibration paper again and
press the ENTER key.
(6) Press the ENTER key to start calibration. Do not move the head and calibration paper during calibration.
Close the acceptor head. Make sure that the tabs on both side of the acceptor head are firmly locked.
