Jconcepts BJ4 - Page 11

COMPARE TRANSMISSION ASSEMBLY
REAR TRANSMISSION ASSEMBLY:
1. ATTACH THE UPPER TRANSMISSION CASE TO THE LOWER
TRANSMISSION CASE WITH FOUR 4-40 x 3/8" SOCKET HEAD
SCREWS AND TWO 4-40 x 3/8" BUTTON HEAD SCREWS.
4-40 x 3/8"
BUTTON HEAD
x 2
4-40 x 3/8"
SOCKET HEAD
x 4
STEP 17
STEP 18
