7
User manual
2- Technical specifications
2.2 Dimensions
Position Description Millimeters
A Dispenser height 562
B Distance from top of dispenser to front of open door 193
C Dispenser width 390
D Dispenser depth 426
E Dispenser height with door open 755
F Dispenser depth with door open 500
G Clearance with drip tray in place 130
H Clearance with drip tray removed 165
A
C
B
D
E
F
G
H
