JDE EXCELLENCE COMPACT TOUCH - Button Functions; Display Overview

9
User manual
3- Part overview description
3.3 Button functions
USB key port
(for service personal)
3.4 Display overview
Icon Area (C) Legend
Water tank empty
No milk, external milk
system
Boiler heating up
Descaling required
Cleaning required
Filter exchange required
Note:
Some options are not available in all markets.
i
Cold water
Hot water
A
B
C
Message area (A) – display messages*, dispensing not possible
Message area (B) – display messages*, dispensing still possible
Icon area (C) – click on any icon to open message area (B)
*See Troubleshooting section for message details.
