1. LED INDICATOR
PROTECT LED
Protect LED light with the protection circuit activated:
1. After switching-on for approx. 3 seconds(in-rush delay)
.
(in-rush 회로작동)
1. LED
2. CHANNEL VOLUME
PROTECT LED
1.전원스위치를켠후3초동안LED가켜지게됩니다.
2.스피커출력단에직류전압이생기면보호회로가작동하며LED가켜지게
3.앰프가과열이되면보호회로가작동하며LED가켜지게됩니다.
CLIP LED
SIGNAL LED
POWER LED
출력신호에일그러짐이발생하면LED가켜지게됩니다.
출력신호의유무를표시하여주는LED입니다.
앰프에전기가공급되고있슴을알려주는LED입니다.
각채널의음량을조절하는볼륨입니다.
3. POWER SWITCH
※주의
브릿지모노운용시에는채널A볼륨으로작동되며채널B볼륨은반시계방향
으로돌려놓고운용하십시오.
기기에전원을공급하는스위치입니다.
켜십시오.
정도기다린후방열판이식으면전원을꺼주시기바랍니다.
1.앰프의전원을켤때는주변음향기기들을먼저켠후에앰프의전원을
2.앰프의전원을끌때는볼륨을반시계방향으로끝까지돌리고,23분
3. If the amplifier is overheated.
2. If a DC voltage is present at a speaker output.
됩니다.
F
RONT PANEL CONTROLS (전면기능)
1
2
3
2
SIGNAL LED
SIGNAL LED light if the output signal exceeds 100mW.
POWER LED
POWER LED as operating light.
2. CANNEL VOLUME
Control for the output level of channel A,B.
3. POWER SWITCH
Provides power to the unit.
switched on.
2~3 minutes before switching off.
For the internal fans continue to cool the unit otherwise the
amplifier maybe damaged.
NOTE:
1. To avoid loud switching noises, always switch on the power
amplifier in an amplifier system after all other units have been
2. At first turn the volume fully counterclockwise. Then wait approx
CLIP LED light with overdrive.
CLIP LED
