GETTING TO KNOW YOUR VEHICLE 49
Center Air Outlets
Right Side Air Outlets
Manual Climate Controls Overview
Manual Climate Controls
Manual Climate Control Descriptions
1 — Fixed Air Outlet
2 — Air Flow Outlet Adjustment
3 — Air Vane Adjustment
4 — Adjustable Air Outlet
1 — Fixed Air Outlet
2 — Adjustable Air Outlet
3 — Air Vane Adjustment
4 — Air Flow Outlet Adjustment
Icon Description
MAX A/C Control
MAX A/C sets the system for maximum cooling performance. Rotate the Temperature Control Knob counterclockwise until
it is set to MAX A/C. In MAX A/C, the blower speed and mode position can be adjusted to desired user settings.
A/C Button
Push the A/C button to engage the Air Conditioning. The A/C LED light illuminates when the A/C is on.
2
20_BV_OM_EN_USC_t.book Page 49
