Cavity Cartridge Fuse Micro Fuse Description
* If Equipped
F04 – 20 Amp Yellow Fuel Pump MTR/FPCM
F05 – 5 Amp Tan Security Gateway
F06 – – Spare*
F07 – – Spare*
F08 – 15 Amp Blue Trans Control Module TCM-8HP CYGNUS
F09 – – Spare*
F10 – 15 Amp Blue
Key Ignition Node (KIN)/Radio Frequency Hub (RF HUB)/Electric
Steering Column Lock (ESCL)
F11 – 10 Amp Red UCI Port (USB & AUX)
F12 – 25 Amp Clear HIFI Amplifier
F13 – – Spare*
F14 – – Spare*
F15 – 15 Amp Blue
Instrument Panel Cluster (IPC)/Switch Bank-Heavy Duty Electrical
Pkg (SWITCH BANK-HD ELEC)
F16 – – Spare*
F17 – – Spare*
F18 – 10 Amp Red Air Conditioning Clutch (AC CLUTCH)
F19 – – Spare*
F20 30 Amp Pink – Central Body Controller (CBC) 1-INTERIOR LIGHTS
F21 – – Spare*
F22 – 10 Amp Red Engine Control Module (ECM)/Powertrain Control Module (PCM)
F23 – 10 Amp Red Powertrain Control Module (PCM)/Engine Control Module (ECM)
F24 – – Spare*
F25 – 10 Amp Red Module Shift By Wire (MOD_SBW)
F26 40 Amp Green – Central Body Controller (CBC) 2-EXTERIOR LIGHTS #1
F27 30 Amp Pink – Front Wipers
SERVICING AND MAINTENANCE 327
