Cavity Cartridge Fuse Micro Fuse Description
* If Equipped
F28 40 Amp Green – Central Body Controller (CBC) 3-POWER LOCKS
F29 40 Amp Green – Central Body Controller (CBC) 4-EXTERIOR LIGHTS #2
F30 – – Spare*
F31 – 10 Amp Red DIAGNOSTIC PORT
F32 – 10 Amp Red
Heating Ventilation Air Conditioning Mod (HVAC CTRL MOD)/Steering
Column Lock (SCL)/Occupant Classification Module (OCM)/Driver
Presence Detection Module (DPDM)
F33 – 10 Amp Red
ParkTronics System (PTS)/Infrared Camera Module (IRCM)/Airbag
Disable Lamps (AIRBAG DISABLE LMPS)
F34 – 10 Amp Red
Electronic Stability Control (ESC)/Electric Hydraulic Power Steering
(EHPS)/Smart Bar Control Module (SBCM) WAKE UP
F35 30 Amp Pink – BRAKE VAC PMP*
F36 30 Amp Pink – Trailer Tow Elec Brk Mod *
F37 30 Amp Pink – TRAILER TOW CONN 7W*
F38 20 Amp Blue – Engine Control Module (ECM)
F39 – – Spare*
F40 – 15 Amp Blue Drivetrain Control Module (DTCM)/Axle Lock (AXLE LOC) FT_RR
F41 – 15 Amp Blue Instrument Cluster (IC)/Security GateWay (SGW) WAKE UP
F42 – 10 Amp Red Power Control Relay Control Feed (Electric Stop/Start)*
F43 – – Spare*
F44 – 10 Amp Red Infrared Camera (IRCAM) HEATERS
F45 – – Spare*
F46 – 10 Amp Red AUTO HDLP LVL MOD/LVL MTR/HDLP SW
F47 – – Spare*
F48 – – Spare*
F49 – 10 Amp Red Occupant Restraint Controller (ORC)
