Jenn-Air JDS8850AAS - User Manual

62 pages

Save Page as PDF

To Next Page

To Next Page

Loading...

16026016

March 2005

©2005 Maytag Services

This Base Manual covers general information

Refer to individual Technical Sheet

for information on specific models

This manual includes, but is

not limited to the following:

Service

This manual is to be used by qualified appliance

technicians only. Maytag does not assume any

responsibility for property damage or personal

injury for improper service procedures done by

an unqualified person.

JDS8850AAB/Q/S/W

JDS8850ACS/W

JDS9860AAB/P/W

JDS9860ACB/P/W

Dual Fuel

Slide-In

Range

Table of Contents

Questions and Answers

T
Teresa DanielAug 7, 2025
What to do if my Jenn-Air Ranges burner won't ignite?
- C
  Carrie Briggs MDAug 7, 2025
  If the burner on your Jenn-Air Ranges isn't igniting, several factors could be at play. First, ensure your range is receiving 120 VAC by verifying the voltage at the wall outlet. A dirty electrode or burner cap can also prevent ignition, so try cleaning them. Other potential causes include faulty wiring or a bad connection at the burner electrode and electrode socket, micro switch contacts not closing, or a non-operative spark module. Check the wiring against the appropriate wiring diagram to ensure all terminals and connections are correct and tight. If the electrode is cracked or broken, replace it. Check the module according to testing procedures information.
R
Rebecca GriffinAug 11, 2025
How to fix Jenn-Air Ranges burners that won't ignite?
- R
  richardglassAug 11, 2025
  If the burners on your Jenn-Air Ranges aren't igniting and there's no spark, it could be due to several reasons. Start by cleaning the burner cap to ensure a good ground. Low gas pressure could also be the culprit; verify the pressure is 4" WCP for natural gas or 10" WCP for LP gas. Additionally, a clogged burner port can prevent ignition, so clean the burner cap. If these steps don't work, the spark module might be weak or has failed and should be replaced.
L
loribatesAug 16, 2025
Why is my Jenn-Air Ranges bake element not working?
- R
  Rhonda FrancoAug 16, 2025
  If the bake element in your Jenn-Air Ranges isn't working, it could be due to an open bake element. Check the element for continuity and replace it if it has failed. Also, inspect for any loose or broken wire connections and ensure all connections are clean and tight, replacing any broken wires. Finally, verify 240 VAC at the bake element to check for an open bake relay.
M
Michael PerryAug 21, 2025
What to do if my Jenn-Air Ranges oven won't bake or broil?
- M
  Michael SimonAug 21, 2025
  If your Jenn-Air Ranges oven isn't operating in bake or broil mode, begin by checking for 120 VAC at the control. If there's no voltage, check the power source. If there is voltage to the control but no voltage from control to the ignitor, the control may need to be replaced. Also, inspect for any loose or broken wires, ensuring all connections are clean and tight; replace any broken wires.
J
Jenna RodriguezAug 27, 2025
Why is there no spark on my Jenn-Air Ranges ignitor?
- B
  Brandon CastroAug 27, 2025
  If you're experiencing no spark or random sparks at one ignitor on your Jenn-Air Ranges, a few things could be the cause. Check for a cracked ignitor or pinched ignitor wire and replace the ignitor lead or electrode if needed. Poor continuity to the burner cap can also be an issue, so clean the burner cap and lead. Additionally, a bad ground connection or lack of continuity to ground or the ignitor can cause this problem. Tighten the ground connection and correct any breaks in the ground path from the ignitor path to the unit ground path. Finally, check for a cracked or broken ignitor extension lead and replace the ignitor lead if necessary.
R
Richard ConnerAug 31, 2025
What to do if Jenn-Air Ranges keeps sparking after being turned off?
- E
  Erik JacksonAug 31, 2025
  If your Jenn-Air Ranges continues to spark after the knob is turned to the OFF position, it could be due to a shorted valve switch or harness. In this case, replace the switch or harness. Also, check if the switch has slipped off the valve; carefully reposition the switch on the valve and rotate it from OFF to high several times to verify the switch is not broken.

Summary

Service Manual Overview

Dual Fuel Slide-In Range

Specifies the type of appliance covered by this service manual.

Important Information

Important Notices for Servicers and Consumers

Crucial warnings and guidance for technicians and users.

Recognize Safety Symbols, Words, and Labels

Explanation of safety symbols and hazard indicators used in the manual.

Important Safety Information

What to Do If You Smell Gas

Step-by-step instructions for handling a gas leak emergency.

General Appliance Safety Precautions

Essential safety guidelines applicable to all appliances.

Servicing Safety

Safety Practices for Servicers

Key safety precautions for appliance repair technicians.

Servicing Guidelines

General precautions and practices for performing service.

Product Safety Features

Pressure Regulator Safety

Explanation of the pressure regulator's function and importance.

Grounded Oven Frame Safety

Ensuring proper grounding for electrical safety.

General Information

Cooking Nomenclature Explained

Decoding the model number and its components.

Model Identification Guide

Information on identifying the specific model of the appliance.

Range Component Description

Troubleshooting Procedures

Troubleshooting Chart

Table listing common problems, causes, and solutions.

Fault Code Diagnostics

Interpreting error codes displayed by the oven control.

Sensor and Probe Specifications

Testing and Diagnostics

Component Testing Procedures

Detailed steps and expected results for testing various components.

Oven Control Diagnostics

Procedures for testing and interpreting oven control functions and errors.

Disassembly Procedures

Range Removal and Replacement

Steps for safely removing and reinstalling the entire range unit.

Maintop and Component Access

Procedures for accessing and removing the cooktop, control panel, and electronic components.

Oven Door Service

Procedures for removing, disassembling, and servicing the oven door.

Installation Instructions

Installation Drawings Overview

Diagrams illustrating installation clearances and requirements.

Anti-Tip Device Installation

Procedures for securing the appliance to prevent tip-over.

Electrical and Gas Connection

Guidelines for connecting the range to electrical power and gas supply.

Downdraft Venting Installation

Rear Wall Venting

Instructions for venting the downdraft blower through the rear wall.

Floor Venting Installation

Steps for venting the downdraft blower through the floor.

Side Cabinet Venting

Instructions for venting the downdraft blower through a side cabinet.

Appliance Operation Guide

Control Pad Operation Basics

How to use the various buttons and pads on the control panel.

Setting Oven Functions

Procedures for programming bake, broil, convection, and timed cooking.

Special Cooking Modes

Using keep warm, meat probe, and bread proofing functions.

Customizing Control Settings

Adjusting timer signals, clock, display, and temperature settings.

Care and Cleaning

Self-Clean Cycle Operation

Instructions for setting and using the self-cleaning cycle.

General Cleaning Procedures

Guidelines for cleaning exterior, interior, and specific parts of the appliance.

Burner and Cooktop Cleaning

How to clean gas burners, grates, stainless steel surfaces, and grease cup.

LP Conversion Instructions

General Gas Conversion Overview

Information on converting the appliance between gas types.

Appliance Pressure Regulator Conversion

Steps to adjust the pressure regulator for different gas types.

Orifice Conversion Procedure

Adjusting orifices and air shutters for correct gas conversion.
