8
DVDB01
Audio/Video Connections
NOTE: When replacing a fuse, be sure to use correct type and amperage to avoid damaging
the DVD player. The DVDB01 uses one 3 amp and one 1 amp ACC fuse, located in line with
the power wires.
YELLOW
WHITE
RED
WHITE
RED
YELLOW
YELLOW
