Jensen JMS4 User Manual

5
JMS4
Note: Do not connect the red wire to a
constant power connection. The red wire
should be connected to a vehicle connection
with switched power such as IGN or ACC.
WIRE COLOR
PURPLE
PURPLE/BLACK
GREEN
GREEN/BLACK
BLUE
BLACK
RED
GRAY
GRAY/BLACK
WHITE
WHITE/BLACK
DESCRIPTION
RIGHT REAR SPEAKER(+)
RIGHT REAR SPEAKER(-)
LEFT REAR SPEAKER(+)
LEFT REAR SPEAKER(-)
POWER AMP REMOTE
GROUND
ACC +12V
RIGHT FRONT SPEAKER(+)
RIGHT FRONT SPEAKER(-)
LEFT FRONT SPEAKER(+)
LEFT FRONT SPEAKER(-)
LINE-OUT-RIGHT
LINE-OUT-LEFT
AUX IN-RIGHT
AUX IN-LEFT
USB
ACC +12V
GROUND
FRONT LEFT SPEAKER(-)
FRONT LEFT SPEAKER(+)
REAR LEFT SPEAKER(+)
REAR LEFT SPEAKER(-)
REAR RIGHT SPEAKER(-)
REAR RIGHT SPEAKER(+)
FRONT RIGHT SPEAKER(-)
FRONT RIGHT SPEAKER(+)
POWER AMP REMOTE
GRAY
GRAY/BLACK
BLACK
YELLOW
YELLOW
BLACK
RED
WHITE/BLACK
GREEN
PURPLE
BLUE
GRAY
BLACK
ANTENNA
WHITE
GRAY
GREEN/BLACK
PURPLE/BLACK
FUSE 15A
Wiring Diagram
PIN NO.
B1
B2
B7
B8
A3
A8
A7
B3
B4
B5
B6
