Jensen Octane XDA92RB User Manual

XDA SERIES
1 5
2
3
4
Audio Inputs and Controls
XDA91RB
XDA92RB
XDA94RB
1
1
2
4
3 52
2
2
3 5
3 5
4
4
Line Output
Line Input
High Level Input
Reset
Do not place anything in this area that
could block the radio waves, as this
may be a problem with your Bluetooth
connection.
3

Jensen Octane XDA92RB Specifications

General

Channels	4
RMS Power @ 4 Ohms	90W x 4
Total Harmonic Distortion (THD)	<0.1%
Frequency Response	10 Hz - 30 kHz
Input Sensitivity	200 mV - 6V
Crossover Type	Variable
Low-Pass Crossover Frequency	50 Hz - 250 Hz
High-Pass Crossover Frequency	50 Hz - 250 Hz
Fuse Rating	30A
Peak Power Output	500W
Signal to Noise Ratio	90dB
Bass Boost	0dB - 12dB @ 45Hz
