Jensen VX3014 Operating Instructions

27
VX3014
General
Reference Supply Voltage ........................................................................................................12V(DC)
Operating Voltage Range......................................................................................... 10.5 - 15.8V(DC)
Max Operating Current ..................................................................................................................... 15A
Grounding System................................................................................... Car Battery Negative Pole
Dimensions(WXHXD)................................................................................178 X 50 X (160+34) mm
Weight(main unit) ............................................................................................................................ 2.0kg
FM
Signal Noise Ratio ........................................................................................................................≥55dB
Residual Noise Sensitivity (S/N=30dB) .............................................................................. 18dBμV
Frequency Response (±3dB) ....................................................................................20Hz~12.5KHz
Station Seeking Level .......................................................................................................20~28dBμV
Distortion ........................................................................................................................................ ≤1.0%
Stereo Separation (1KHz) ..........................................................................................................≥25dB
Antenna Impedance ........................................................................................................................75Ω
AM
Residual Noise Sensitivity (S/N=20dB) .............................................................................. 30dBμV
Selectivity (±9KHz).......................................................................................................................≥50dB
LCD
Screen size ....................................................................................................................... 7 inches(16:9)
Display resolution ...........................................................................................................800X480dots
Contrast ratio.................................................................................................................................4000:1
DVD Player
Signal / Noise Ratio.........................................................................................................................80dB
Dynamic Range................................................................................................................................80dB
Distortion (line out) ..................................................................................................................... ≤0.1%
Frequency Response (±3dB) ....................................................................................... 20Hz~20KHz
Maximum Output Power..........................................................................................................4×40W
Load Impedance.................................................................................................................................. 4Ω
AUX IN
Distortion ........................................................................................................................................ ≤0.5%
Frequency Response (±3dB) ....................................................................................... 20Hz~20KHz
Audio Input Level......................................................................................................................0.5Vrms
Audio
Audio Output Impedance........................................................................................................... 100Ω
Audio Output Level .......................................................................................................... 2Vrms(Max)
Video
Normal Video Input Level (CVBS) .......................................................................................1.0±0.2V
Video Input Impedance ..................................................................................................................75Ω
Video Output Impedance...............................................................................................................75Ω
Video Output Level..................................................................................................................1.0±0.2V
Environment
Operating Temperature .............................................................................................. -10°C ~ +60°C
Storing Temperature .................................................................................................... -20°C ~ +70°C
Operating Humidity .......................................................................................................45%~80%RH
Storing Humidity.............................................................................................................30%~90%RH
Notice:
When the unit is operated to extremes, such as with maximum power output for a long time, or the
temperature is over 70°C, it will enter heat protection mode, the volume will be reduced automatically. This
is normal.
6SHFL¿FDWLRQV

Jensen VX3014 Specifications

General

Brand	Jensen
Model	VX3014
Category	Car Receiver
Language	English
