1. Locate the Interface Cover on the front of the radio.
3.5mmA/V Cable (not included)
Video
Left Audio
Right Audio
Ground
1
2
3
4
USB Cable (not included)
USB Slot and microSD Card Slot Location
2.
Lift the protective cover to reveal the USB slot.
3. Insert the USB device into the USB port.
MicroSD card slot
USB / MicroSD Card OPERATION
The unit will read the audio/video files on USB / MicroSD card devices
automatically.
NOTE: The USB port will recognize most USB flash memory devices and
portable hard drives. Hard drives must be formatted to FAT32. NTFS is not
supported. Up to 32GB SD cards are supported.
Inserting / Removing a USB / MicroSD card Device
To insert a USB device:
